Manifold block M5, PWIS-free VABM-C12-6M-M5-M3-10 - Festo 8122794
Festo manifold block VABM-C12-6M-M5-M3-10 for valve groups with a shared compressed-air supply. Supply port 1 in M5 and exhaust port 3 in M5, operating pressure -1 to 7 bar. Type VABM-C12-6M-M5-M3-10 in wrought aluminium alloy.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo manifold block VABM-C12-6M-M5-M3-10 combines valves into one group with a shared compressed-air supply. Ports: supply port 1 in M5, exhaust port 3 in M5 and working port 2 in M3. Permitted operating pressure -1 to 7 bar, the vacuum range included. PWIS conformity to VDMA 24364-Zone III, RoHS compliant.
Benefits
- Supply: Port 1 in M5, exhaust in M5
- Working ports: M3 directly on the block
- Pressure range: -1 to 7 bar, vacuum included
- Material: Wrought aluminium alloy
- PWIS-free: VDMA 24364-Zone III
Applications
Type of mounting: with through-hole, any mounting position. Version: connection direction underneath. As the operating pressure extends to -1 bar, the manifold block also suits vacuum circuits.
Technical data
| Type | VABM-C12-6M-M5-M3-10 |
|---|---|
| Festo part number | 8122794 |
| Width | 20 mm |
| Mounting position | Any |
| Design | Connection direction underneath |
| Maximum number of valve positions | 10 |
| Operating pressure | -1 to 7 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [6:4:1] |
| Note on operating and pilot medium | Maximum particle size 5 µm |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 5 to 50 °C |
| Product weight | 49.5 g |
| Type of mounting | With through-hole |
| Pneumatic connection, port 1 | M5 |
| Pneumatic connection, port 2 | M3 |
| Pneumatic connection, port 3 | M5 |
| Note on materials | RoHS compliant |
| Material manifold rail | Wrought aluminium alloy |
| Weight (shipping) | 0.055 kg |
| Weight | 0.055 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VABM-C12-6M-M5-M3-10 |
| EAN | 4052568550967 |
| Zolltarifnummer | 84819000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | M5 |
| Series | VABM |
| Betriebsdruck max [bar] | 7 |
| Pneumatic connection | M5 |
