Manifold block for 5 valves, 27.5 mm grid, 3/8 NPT VABM-B10-25S-N38-5-P3 - Festo 8026309

Festo ✓ Original product Brand new

5 valve positions on a 27.5 mm grid save individual tubing, the supply runs centrally through the block. Supply port 1 in 3/8 NPT and exhaust port 3 in 3/8 NPT. Type VABM-B10-25S-N38-5-P3 in wrought aluminium alloy, CRC 2.

Net
€80.46
excl. VAT
Item FES-8026309
Manufacturer no. VABM-B10-25S-N38-5-P3
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With 5 valve positions on a 27.5 mm grid, the manifold block VABM-B10-25S-N38-5-P3 forms the base of a compact valve group. Lines connect via supply port 1 in 3/8 NPT and exhaust port 3 in 3/8 NPT. The VABM-B10-25S-N38-5-P3 is made of wrought aluminium alloy, corrosion resistance class 2, VDMA 24364-B1/B2-L.

Benefits

  • Valve positions: 5 positions on a 27.5 mm grid
  • Supply: Port 1 in 3/8 NPT, exhaust in 3/8 NPT
  • Material: Wrought aluminium alloy, CRC 2
  • PWIS-free: VDMA 24364-B1/B2-L

Applications

The VABM-B10-25S-N38-5-P3 is mounted with through-hole, in any position.

Technical data

TypeVABM-B10-25S-N38-5-P3
Festo part number8026309
Grid dimension27.5 mm
Mounting positionAny
Maximum number of valve positions5
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Product weight726 g
Type of mountingWith through-hole
Pneumatic connection, port 13/8 NPT
Pneumatic connection, port 33/8 NPT
Note on materialsRoHS compliant
Material manifold railWrought aluminium alloy
Weight (shipping)1.1 kg
Weight1.1 kg
ManufacturerFesto
Hersteller-NrVABM-B10-25S-N38-5-P3
EAN4052568427702
Zolltarifnummer84819000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadNPT 3/8
Anzahl Stationen [Stk]5
SeriesVABM
Pneumatic connectionNPT 3/8
