Pneumatic interface for Type 44, VTSA, Type 45, VTSA-F VABA-S6-1-X5-F4 - Festo 8154039

Festo ✓ Original product Brand new

The pneumatic interface VABA-S6-1-X5-F4 forms the interface to the valve terminal Type 44, VTSA, Type 45, VTSA-F. Valve positions: 16 with double solenoid valves, 32 with single solenoid valves.

Net
€374.49
excl. VAT
Item FES-8154039
Manufacturer no. VABA-S6-1-X5-F4
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Festo pneumatic interface VABA-S6-1-X5-F4 (material aluminium), part number 8154039.

Benefits

  • Material aluminium: pneumatic interface VABA-S6-1-X5-F4, CRC 0.
  • Mounting: VABA-S6-1-X5-F4 via through-hole for M6 screw.
  • Diagnostics: the VABA-S6-1-X5-F4 reports communication error, short-circuit/overload in output signal, electronics/sensors overvoltage, load overvoltage, electronics/sensors undervoltage, load undervoltage.

Application

The VABA-S6-1-X5-F4 is used on Festo valve terminals with electrical control, for example in assembly and packaging systems. Permissible ambient temperature -20 to 50 °C. LABS (PWIS) conformity to VDMA24364-B2-L.

Technical data

TypeVABA-S6-1-X5-F4
Festo part number8154039
Vibration resistanceTransport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Note on vibration resistanceSG2 on wall mounting
Shock resistanceShock test with severity level 2 to FN 942017-5 and EN 60068-2-27
Note on shock resistanceSG2 on wall mounting
Valve terminal interfaceType 44, VTSA, Type 45, VTSA-F
Reverse polarity protectionYes
Diagnostics via LEDDiagnostics per module, Load power supply
Diagnostics per internal communicationCommunication error, Short-circuit/overload in output signal, Electronics/sensors overvoltage, Load overvoltage, Electronics/sensors undervoltage, Load undervoltage
Number of valve positions (max.)16 with double solenoid valves, 32 with single solenoid valves
Number of valve coils (max.)32
Module code (hex/dec)0x3045/12357d
Module parametersActivation of diagnostics in case of overload/short circuit, Condition counter limit value/actual value, Configuration of voltage monitoring load supply PL, Behaviour in error state
Internal cycle time< 1 ms
Dimensions (W x L x H)70.5 mm x 160.65 mm x 102.6 mm
Fuse protection (short circuit)Internal electronic fuse protection per valve output
Intrinsic current consumption at nominal operating voltage for electronics/sensorsTypical 27 mA
Intrinsic current consumption at nominal operating voltage loadTypical 17 mA
Note regarding operating voltageSELV/PELV fixed power supplies required, Note the voltage drop
Power supply (max.)2 x 16 A (external fuse required)
Nominal DC operating voltage, electronics/sensors24 V
Nominal operating voltage DC of load24 V
Nominal current16 A
Power failure bridging10 ms
Potential separation between the supply voltages electronics/sensor technology and load/valvesYes
Pollution degree2
Permissible voltage fluctuations for electronics/sensors±25%
Permissible voltage fluctuation of load±10%
Power supply, functionIncoming electronics/sensors and load and functional earth
Power supply, connection typePlug
Power supply, connection systemPush-pull to IEC 61076-3-126
Power supply, number of pins/wires5
Power supply, connection pattern00997378
Power transmission, functionOutgoing electronics/sensors and load and functional earth
Power transmission, connection typeSocket
Power transmission, connection technologyPush-pull to IEC 61076-3-126
Power transmission, number of pins/wires5
Power transmission, plug pattern00997378
Undervoltage load/valves (diagnostic message)21.6 V
Corrosion resistance class CRC0 - No corrosion stress
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-20 to 70 °C
Relative air humidity5 - 95%, Non-condensing
Protection classIII
Overvoltage categoryII
Ambient temperature-20 to 50 °C
Note on ambient temperatureObserve ambient temperature derating according to IEC 61131-2:2017
Nominal altitude of use<= 2000 m ASL (> 79.5 kPa)
Installation height (max.)3500 m
Note on max. installation height> 2000 m ASL (< 79.5 kPa), Observe ambient temperature derating according to IEC 61131-2:2017
Product weight1328 g
Electrical controlFieldbus
Communication interface, protocolAP
Mounting typeVia through-hole for M6 screw
Note on materialsRoHS compliant, Free of halogen, Free of phosphoric acid ester
Cover materialZinc die-cast metal, powder-coated
Material sealsNBR, PUR
Material flangeNickel-plated die-cast zinc
Housing materialAluminium
Material screwsNickel-plated steel
Weight (price list)1.3 kg
Weight1.3 kg
ManufacturerFesto
Hersteller-NrVABA-S6-1-X5-F4
EAN4052568614935
Zolltarifnummer85389099
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Seal materialNBR, PUR
SeriesVABA
Temperaturbereich-20-50 °C
Temperature (max.)50
