Washer, DIN 9021, M 24 (26x72mm), zinc-plated steel, inside diameter D 26 mm
When used as a washer, the article spreads the preload of the screw over a larger bearing surface, rating outside diameter D1 72 mm. Decisive here are outside diameter D1 72 mm and inside diameter D 26 mm.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The washer version spreads the preload of the screw over a larger bearing surface, rating outside diameter D1 72 mm. Selection is based on outside diameter D1 72 mm and inside diameter D 26 mm. It is manufactured from zinc-plated steel, in this case with outside diameter D1 72 mm.
Benefits
- manufactured to DIN 9021
- inside diameter D 26 mm
- for screws M 24
- thickness S 5 mm
- larger bearing surface under head and nut, verified by outside diameter D1 72 mm
- material zinc-plated steel as stated in the data
Fields of application
It finds its place in bolted joints in machine, plant and fixture construction, rating outside diameter D1 72 mm.
Standards and conformity
The article complies with DIN 9021.
Technical data
| material | zinc-plated steel |
|---|---|
| for screws | M 24 |
| inside diameter D [mm] | 26 |
| outside diameter D1 [mm] | 72 |
| thickness S [mm] | 5 |
| Weight | 0.105 kg |
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | 9021-24 |
| EAN | 4070497026674 |
| Zolltarifnummer | 73181900 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Stärke S [mm] | 5 |
| Norm | DIN 9021 |
