Magnetoresistive proximity sensor for T-slot 2-wire N/O 2.5 m cable with M8x1 plug in-line outlet SMT-8M-A-ZS-24V-E-2,5-M8D - Festo 577381
Detects the piston magnet without contact using the magnetoresistive principle and signals the cylinder position in drives with T-slot. 2-wire output, N/O, 24 V operating voltage. Connection via 2.5 m cable with M8x1 plug, cable drag chain and robot.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo magnetoresistive proximity sensor SMT-8M-A-ZS-24V-E-2,5-M8D senses end positions and intermediate positions on pneumatic cylinders and grippers and fits into the T-slot. The data below is taken from the Festo type code.
Benefits
- Cable drag chain and robot
- In-line cable outlet, 2.5 m cable with M8x1 plug
- 2-wire output, N/O
Applications
A common application is end position sensing on cylinders with magnetic pistons in assembly and handling systems.
Technical data
| Feature | Value |
|---|---|
| Type | SMT-8M-A-ZS-24V-E-2,5-M8D |
| Festo part number | 577381 |
| Measuring principle | magnetoresistive |
| Design | for T-slot |
| Switching output | contactless, 2-wire |
| Switching element function | N/O contact |
| Rated operating voltage DC | 24 V |
| Electrical connection, connection type | cable with plug |
| Electrical connection, connector system | M8x1 |
| Cable length | 2.5 m |
| Connection outlet direction | in-line |
| Cable characteristic | drag chain and robot |
| Weight | 0.035 kg |
| Manufacturer | Festo |
| Hersteller-Nr | SMT-8M-A-ZS-24V-E-2,5-M8D |
| Zolltarifnummer | 85365019 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Operating voltage | 24 V DC |
| Series | SMT |
