Magnetoresistive proximity sensor for C-slot NPN N/O 0.3 m cable with M8x1 plug lateral outlet SMT-10G-NS-24V-E-0,3Q-M8D - Festo 8065029
Detects the piston magnet without contact using the magnetoresistive principle and signals the cylinder position in drives with C-slot. Connection via 0.3 m cable with M8x1 plug, cable suitable for energy chains, suitable for robots. A yellow LED shows the switching status directly on the sensor.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo magnetoresistive proximity sensor SMT-10G-NS-24V-E-0,3Q-M8D senses end positions and intermediate positions on pneumatic cylinders and grippers and fits into the C-slot.
Benefits
- 0.2 mm repetition accuracy of the switching point
- Up to 150 Hz switching frequency
- Cable suitable for energy chains, suitable for robots, TPE-U(PU) sheath
- 100 mA output current
- Lateral cable outlet, 0.3 m cable with M8x1 plug
Applications
The SMT-10G-NS-24V-E-0,3Q-M8D suits drives with a magnetic piston such as compact and standard cylinders, slides and grippers. Mounting clamped in C-slot, inserted into the slot lengthwise.
Technical data
| Feature | Value |
|---|---|
| Type | SMT-10G-NS-24V-E-0,3Q-M8D |
| Festo part number | 8065029 |
| Design | for C-slot |
| Based on standard | EN 60947-5-2 |
| Approval | RCM mark, c UL us - Listed (OL) |
| CE mark (see declaration of conformity) | to EU EMC Directive, to EU RoHS Directive |
| UKCA marking (see declaration of conformity) | to UK RoHS regulations |
| Certificate issuing authority | UL E232949 |
| Note on materials | RoHS-compliant |
| Measured variable | position |
| Measuring principle | magnetoresistive |
| Ambient temperature | -20 to 70 °C |
| Repetition accuracy | 0.2 mm |
| Switching output | NPN |
| Switching element function | N/O contact |
| Switch-on time | 1 ms |
| Switch-off time | 1 ms |
| Max switching frequency | 150 Hz |
| Max output current | 100 mA |
| Max switching capacity DC | 2.8 W |
| Voltage drop | 2 V |
| Inductive protective circuit | adapted to MZ, MY and ME coils |
| Off-state current | 0.15 mA |
| Short circuit protection | yes |
| Overload protection | yes |
| Rated operating voltage DC | 24 V |
| Operating voltage range DC | 10 to 30 V |
| Residual ripple | 10 % |
| Reverse polarity protection | for all electrical connections |
| Electrical connection, connection type | cable with plug |
| Electrical connection, connector system | M8x1, A-coded to EN 61076-2-104 |
| Electrical connection, number of pins/wires | 3 |
| Electrical connection, type of mounting | screw-type lock with hexagon AF 9 and longitudinal knurl, rotatable |
| Electrical connection, compatible type of mounting | compatible with rotatable or non-rotatable screw-type lock |
| Electrical connection, connection pattern | 00991155 |
| Connection outlet direction | lateral |
| Material contacts | brass, gold-plated |
| Material connector housing | TPE-U(PU) |
| Material screw-type lock | brass, nickel-plated |
| Cable test conditions | bending strength to Festo standard, test conditions on request, torsional strength above 300 000 cycles, ±270°/0.1 m, energy chain above 5 million cycles, bending radius 28 mm |
| Cable length | 0.3 m |
| Cable characteristic | suitable for energy chains, suitable for robots |
| Cable sheath colour | grey |
| Cable sheath material | TPE-U(PU) |
| Type of mounting | clamped in C-slot, inserted into the slot lengthwise |
| Max tightening torque | 0.6 Nm |
| Mounting position | any |
| Housing colour | black |
| Housing material | high-alloy stainless steel |
| Switching status indication | yellow LED |
| Ambient temperature with moving cable | -5 to 70 °C |
| Degree of protection | IP65, IP68 |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Suitability for the production of Li-ion batteries | suitable for battery production with reduced Cu/Zn/Ni values (F1a) |
| Cleanroom suitability to ISO 14644-14 | statically installed element, no meaningful evaluation possible to ISO 14644-1 |
| Weight | 0.015 kg |
| Manufacturer | Festo |
| Hersteller-Nr | SMT-10G-NS-24V-E-0,3Q-M8D |
| EAN | 4052568290801 |
| Zolltarifnummer | 85365019 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Colour | Black |
| Norm | DIN EN 61076-2-104, DIN EN 60947-5-2 |
| Operating voltage | 24 V DC |
| Series | SMT |
| Protection rating | IP65 |
| Temperaturbereich | -20-70 °C |
| Temperature (max.) | 70 |
