Reed proximity sensor contacting N/O 0.4 m cable with M12x1 plug in-line outlet SME-8M-DS-24V-K-0.4-M12 - Festo 577105
The reed contact switches as soon as the piston magnet passes it, signalling the cylinder position. Contacting switch, N/O, 24 V operating voltage. Connection via 0.4 m cable with M12x1 plug, cable standard and drag chain.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo reed proximity sensor SME-8M-DS-24V-K-0.4-M12 senses end positions and intermediate positions on pneumatic cylinders and grippers. The data below is taken from the Festo type code.
Benefits
- Cable standard and drag chain
- In-line cable outlet, 0.4 m cable with M12x1 plug
- Contacting switching output, N/O
Applications
The SME-8M-DS-24V-K-0.4-M12 suits drives with a magnetic piston such as compact and standard cylinders, slides and grippers.
Technical data
| Feature | Value |
|---|---|
| Type | SME-8M-DS-24V-K-0.4-M12 |
| Festo part number | 577105 |
| Measuring principle | magnetic reed |
| Switching output | contacting, bipolar |
| Switching element function | N/O contact |
| Rated operating voltage DC | 24 V |
| Electrical connection, connection type | cable with plug |
| Electrical connection, connector system | M12x1 |
| Cable length | 0.4 m |
| Connection outlet direction | in-line |
| Cable characteristic | standard and drag chain |
| Weight | 0.023 kg |
| Manufacturer | Festo |
| Hersteller-Nr | SME-8M-DS-24V-K-0.4-M12 |
| Zolltarifnummer | 85365019 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Operating voltage | 24 V DC |
| Series | SME |
