With 12 stations this terminal box with jump module bundles the valves of a machine in one place. The supply is 24 V DC.
Terminal box with jump module, 12 stations, 24 V DC, protection class IP 40
YPC
Original product
Net price (excl. VAT)
€261.05
Item
FL-248614
Manufacturer no.
MCS421-12
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.MCS421-12
EAN4050571483197
Customs tariff number85365019
ConditionNew
Artikel
FL-248614
Frequently Bought Together
-
This Item:
€261.05
-
Mini elbow flow control valve with check function, exhaust air control (standard), R 1/8", tube 6 mm
€10.37
-
Valve terminal, 4 stations, EtherCAT, outlets M 5 at base plate (side), 8x M 5, 24 V DC
€1,160.83
Total price
This terminal box with jump module groups 12 valve stations and thus shortens piping and wiring in the control cabinet. The supply is 24 V DC. The power consumption is 2.5 W / station. The protection class is IP 40.
Advantages
- Protection class IP 40, suitable for mounting at the machine.
- Dimensions A 358.5, B 346.5, so the space requirement can be planned in advance.
- Capacity for 12 valve stations, so the terminal grows with the plant.
- Supply with 24 V DC at 2.5 W / station, which keeps the load on the power supply manageable.
Technical data
| Feature | Value |
|---|---|
| Description | Terminal box with jump module |
| Number of stations [pcs] | 12 |
| Dimensions [mm] | A 358.5, B 346.5 |
| Control voltages | 24 V DC |
| Voltage tolerance | plus/minus 10 percent |
| Power consumption | 2.5 W / station |
| Protection class | IP 40 |
Applications
- Retrofitting and extending existing valve islands.
- Special purpose machinery with a changing number of actuators.
- Machines with up to 12 pneumatic axes in one place.
| Weight | 0.750000 |
|---|---|
| Manufacturer | YPC |
| Hersteller-Nr | MCS421-12 |
| EAN | 4050571483197 |
| Zolltarifnummer | 85365019 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Anzahl Stationen [Stk] | 12 |
