Pressure sensor 0 to 10 bar, PNP, push-in connector QS-4 SDE5-D10-O-Q4E-P-K-4X - Festo 573187
The pressure sensor SDE5-D10-O-Q4E-P-K-4X detects relative pressure in the range 0 to 10 bar and switches via a PNP switching output. Push-in connector QS-4 and 2.5 m cable (3-wire). Weight according to the price list 115 g, Festo part number 573187.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Measuring range 0 to 10 bar: the Festo pressure sensor SDE5-D10-O-Q4E-P-K-4X detects relative pressure and switches via a PNP switching output.
Benefits
- Measuring range 0 to 10 bar
- Push-in connector QS-4, electrical: 2.5 m cable (3-wire)
- PNP switching output, N/O contact
Application
This allows supply pressure, test pressure and pressure drop on machines to be monitored directly.
Technical data
| Type | SDE5-D10-O-Q4E-P-K-4X |
|---|---|
| Pressure measuring range initial value | 0 bar |
| Pressure measuring range full scale value | 10 bar |
| Measured variable | Relative pressure |
| Switching function | Threshold value with fixed hysteresis |
| Switching element function | N/O contact |
| Pneumatic connection | QS-4 |
| Switching output | PNP |
| Electrical connection | 3-wire, cable |
| Cable length | 2.5 m |
| Weight (price list) | 115 g |
| Weight | 0.115 kg |
| Manufacturer | Festo |
| Hersteller-Nr | SDE5-D10-O-Q4E-P-K-4X |
| Zolltarifnummer | 90262020 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Measuring range max. [bar] | 10 |
| Function | NO contact |
