Hall effect proximity sensor for T-slot PNP/NPN switchable N/O or N/C switchable 0.3 m cable with M8x1 plug SDBT-MSX-1L-PU-E-0.3-N-M8 - Festo 8059120
Detects the piston magnet without contact using the Hall effect and signals the cylinder position in drives with T-slot. Connection via 0.3 m cable with M8x1 plug, cable suitable for energy chains, suitable for robots. A yellow LED shows the switching status directly on the sensor.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo hall effect proximity sensor SDBT-MSX-1L-PU-E-0.3-N-M8 senses end positions and intermediate positions on pneumatic cylinders and grippers and fits into the T-slot.
Benefits
- 0.1 mm repetition accuracy of the switching point
- Up to 200 Hz switching frequency
- Cable suitable for energy chains, suitable for robots, TPE-U(PUR) sheath
- 100 mA output current
- In-line cable outlet, 0.3 m cable with M8x1 plug
Applications
The SDBT-MSX-1L-PU-E-0.3-N-M8 suits drives with a magnetic piston such as compact and standard cylinders, slides and grippers. Mounting screwed tight, insertable into the slot from above.
Technical data
| Feature | Value |
|---|---|
| Type | SDBT-MSX-1L-PU-E-0.3-N-M8 |
| Festo part number | 8059120 |
| Design | for T-slot |
| Based on standard | EN 60947-5-2 |
| Approval | RCM mark, c UL us - Listed (OL) |
| CE mark (see declaration of conformity) | to EU EMC Directive, to EU RoHS Directive |
| UKCA marking (see declaration of conformity) | to UK RoHS regulations |
| Certificate issuing authority | UL E232949 |
| Note on materials | RoHS-compliant, halogen-free |
| Measured variable | position |
| Measuring principle | magnetic Hall |
| Ambient temperature | -40 to 85 °C |
| Max travel speed | 3 m/s |
| Repetition accuracy | 0.1 mm |
| Switching output | PNP/NPN switchable |
| Switching element function | N/O or N/C, switchable |
| Hysteresis | 0.2 mm |
| Switch-on time | 2 ms |
| Switch-off time | 2 ms |
| Max switching frequency | 200 Hz |
| Max output current | 100 mA |
| Max output current in mounting kits | 100 mA |
| Max switching capacity DC | 2.8 W |
| Max switching capacity DC in mounting kits | 2.8 W |
| Voltage drop | 1.5 V |
| Min load current | 0.15 mA |
| Off-state current | 0.2 mA |
| Short circuit protection | yes |
| Overload protection | yes |
| Rated operating voltage DC | 24 V |
| Operating voltage range DC | 10 to 30 V |
| Reverse polarity protection | for all electrical connections |
| Electrical connection, connection type | cable with plug |
| Electrical connection, connector system | M8x1, A-coded to EN 61076-2-104 |
| Electrical connection, number of pins/wires | 3 |
| Electrical connection, type of mounting | screw-type lock, rotatable |
| Electrical connection, compatible type of mounting | compatible with rotatable or non-rotatable screw-type lock |
| Electrical connection, connection pattern | 00991155 |
| Connection outlet direction | in-line |
| Material screw-type lock | brass, nickel-plated |
| Cable test conditions | bending strength to Festo standard, test conditions on request, torsional strength above 300 000 cycles, ±270°/0.1 m, energy chain above 5 million cycles, bending radius 28 mm |
| Cable length | 0.3 m |
| Cable characteristic | suitable for energy chains, suitable for robots |
| Cable sheath colour | grey |
| Cable sheath material | TPE-U(PUR) |
| Type of mounting | screwed tight, insertable into the slot from above |
| Max tightening torque | 0.6 Nm |
| Mounting position | any |
| Housing colour | black |
| Housing material | reinforced PA, high-alloy stainless steel |
| Switching status indication | yellow LED |
| Status indication | green LED |
| Setting options | auto teach-in, capacitive button |
| Ambient temperature with moving cable | -20 to 85 °C |
| Degree of protection | IP65, IP68, IP69K |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Suitability for the production of Li-ion batteries | suitable for battery production with reduced Cu/Zn/Ni values (F1a) |
| Cleanroom suitability to ISO 14644-14 | statically installed element, no meaningful evaluation possible to ISO 14644-1 |
| Weight | 0.025 kg |
| Manufacturer | Festo |
| Hersteller-Nr | SDBT-MSX-1L-PU-E-0.3-N-M8 |
| EAN | 4052568300449 |
| Zolltarifnummer | 85365019 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Colour | Black |
| Norm | DIN EN 61076-2-104, DIN EN 60947-5-2 |
| Operating voltage | 24 V DC |
| Series | SDBT |
| Protection rating | IP65 |
| Temperature (max.) | 85 |
