This angle seat valve shuts off liquids, steam and gases in an inclined seat with a low pressure drop. A key figure is a working pressure range of 0 - 16 bar. Size G 1", 80 mm, open, standard, material brass.
Angle seat valve, pneumatic, G 1", brass, normally open, standard
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€263.04
Item
FL-029219
Manufacturer no.
UO 210 MS
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.UO 210 MS
EAN4050571713430
Customs tariff number84812090
ConditionNew
Artikel
FL-029219
Frequently Bought Together
-
This Item:
€263.04
-
Angle seat valve, pneumatic, G 3/4", 1.4408, normally closed, closing against flow
€288.05
-
Angle seat valve, pneumatic, G 1-1/4", brass, normally closed, PTFE stem seal, 0 - 10 bar
€269.53
Total price
Once installed, the angle seat valve shuts off liquids, steam and gases in an inclined seat with a low pressure drop. Material brass is listed for this version. The data state a working pressure range of 0 - 16 bar. Also stated are the normal position open and the version standard.
Benefits
- Working pressure range 0 - 16 bar at connection G 1".
- Medium temperature -10 to +80 °C at an ambient temperature of -10 to +60 °C.
- Installation length 80 mm, valve body in brass.
- Control pressure 4 to 10 bar, 6 bar as the optimum, control port G 1/8 inch.
- Normal position open in the standard version.
Technical data
| Material | brass |
|---|---|
| Version | standard |
| Normal position | open |
| Connection thread | G 1" |
| Installation length L [mm] | 80 |
| Working pressure [bar] | 0 - 16 |
| Medium temperature [°C] | -10 to +80 |
| Ambient temperature [°C] | -10 to +60 |
| Control pressure | 4 - 10 bar (6 bar optimum) |
| Control connection | G 1/8 inch |
| Seat seal | PTFE |
Applications
In cleaning and filling plants the valve of 80 mm installation length and the normal position open sits in the line.
Standards and conformity
The control pressure is 4 to 10 bar, 6 bar as the optimum, and the control port is G 1/8 inch. The seat seal is made of PTFE.
| Weight | 1.500000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | UO 210 MS |
| EAN | 4050571713430 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Standard |
| Material | Brass |
| Thread | G 1 |
| Medientemperatur [°C] | -10 bis +80 |
