In service the angle seat valve shuts off liquids, steam and gases in an inclined seat with a low pressure drop. The decisive figure is a working pressure range of 0 - 16 bar. Material brass, size G 1-1/4", 97 mm, closed, standard.
Angle seat valve, pneumatic, G 1-1/4", brass, normally closed, standard, 0 - 16 bar
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€286.07
Item
FL-015763
Manufacturer no.
U 2114 MS
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.U 2114 MS
EAN4050571711672
Customs tariff number84812090
ConditionNew
Artikel
FL-015763
Frequently Bought Together
-
This Item:
€286.07
-
Angle seat valve, pneumatic, G 1/2", brass, normally closed, PTFE stem seal
€160.84
-
Angle seat valve, pneumatic, G 1/2", 1.4408, normally closed, closing against flow, FKM
€413.99
Total price
This angle seat valve shuts off liquids, steam and gases in an inclined seat with a low pressure drop. This version comes with connection G 1-1/4" and installation length 97 mm. A further figure is a medium temperature of -10 to +80 °C. This version is supplied with the normal position closed and the version standard.
Benefits
- Working pressure range 0 - 16 bar at connection G 1-1/4".
- Medium temperature -10 to +80 °C at an ambient temperature of -10 to +60 °C.
- Installation length 97 mm, valve body in brass.
- Control pressure 4 to 10 bar, 6 bar as the optimum, control port G 1/8 inch.
- Normal position closed in the standard version.
Technical data
| Material | brass |
|---|---|
| Version | standard |
| Normal position | closed |
| Connection thread | G 1-1/4" |
| Installation length L [mm] | 97 |
| Working pressure [bar] | 0 - 16 |
| Medium temperature [°C] | -10 to +80 |
| Ambient temperature [°C] | -10 to +60 |
| Control pressure | 4 - 10 bar (6 bar optimum) |
| Control connection | G 1/8 inch |
| Seat seal | PTFE |
Applications
In cleaning and filling plants the valve of 97 mm installation length and the normal position closed sits in the line.
Standards and conformity
The control pressure is 4 to 10 bar, 6 bar as the optimum, and the control port is G 1/8 inch. The seat seal is made of PTFE.
| Weight | 2.200000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | U 2114 MS |
| EAN | 4050571711672 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Standard |
| Material | Brass |
| Thread | G 1 1/4 |
| Medientemperatur [°C] | -10 bis +80 |
