With the bulkhead tube fitting the joint is made at one point, the bulkhead thread M 20x1.5 meets a tube of 14x12 mm. Tube 14x12 mm, bulkhead design, material PVDF.
Bulkhead tube fitting, bulkhead design, bulkhead thread M 20x1.5, tube 14x12 mm, PVDF
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€78.96
Item
FL-013136
Manufacturer no.
SCK 12 PVDF
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SCK 12 PVDF
EAN4050571615819
Customs tariff number39174000
ConditionNew
Artikel
FL-013136
Frequently Bought Together
-
This Item:
€78.96
-
Tube fitting, straight design, male thread R 1/8", tube 6x4 mm, PVDF
€8.19
-
Push-in fitting, male thread G 1/4", tube 10 mm, nickel plated brass, -20 bis +70 °C
€8.09
Total price
The temperature range reaches from -40 °C to +140 °C. The bulkhead tube fitting connects the bulkhead thread M 20x1.5 and a tube of 14x12 mm in doing so. The bulkhead design leads the line tightly through a panel or wall.
Benefits
- The bulkhead panel may be up to 19 mm thick
- The design follows connection principle 1 of the range
- Approvals to FDA are documented for the materials
- Union nut and clamping ring allow the joint to be released repeatedly
- The connection over bulkhead thread M 20x1.5 is fixed in size and needs no adaptor
Technical data
| Material | PVDF |
|---|---|
| Tube diameter (outside x inside) | 14x12 mm |
| Maximum bulkhead panel thickness | 19 mm |
| Bulkhead thread | M 20x1.5 |
| Connection principle | connection principle 1 |
| Temperature range | -40 to +140 °C |
| Material approvals | FDA |
Applications
Tube lines in pneumatics, water lines on machines, laboratory equipment and dosing technology, plant construction with frequent modification.
Standards and conformity
The following approvals are documented for the materials used: FDA.
| Weight | 0.046000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | SCK 12 PVDF |
| EAN | 4050571615819 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PVDF |
| Schlauchdurchmesser (außen x innen) [mm] | 14x12 |
| Temperaturbereich | -40-140 °C |
