Push-in fitting, bulkhead design, thread M 17x1, tube 10 mm, nickel plated brass

The push-in fitting connects the bulkhead thread M 17x1 and a tube of 10 mm outside diameter. The temperature range reaches from -20 °C to +150 °C. The bulkhead design leads the line tightly through a panel or wall.

Benefits

• The connection over bulkhead thread M 17x1 is fixed in size and needs no adaptor
• With tube diameter 10 mm the size is fixed, so no reworking of the line is required
• The temperature range from -20 °C to +150 °C covers cold installation and warm machine surroundings
• Nickel plated brass as material covers the released range from -20 °C to +150 °C

Technical data

Applications

Compressed air installation on machines and plants, pneumatic cylinders and valve terminals, control air lines inside the control cabinet, workshop distribution and service units.

Standards and conformity

Only silicone free seals and lubricants are used during assembly.
