With the push-in fitting the joint is made at one point, a tube of 15 mm outside diameter meets the continuing line. Large design, elbow design, tube diameter 15 mm.
Push-in fitting, elbow design, large design, tube 15 mm, POM
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€8.23
Item
FL-012105
Manufacturer no.
IQSL 150
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.IQSL 150
EAN4050571378646
Customs tariff number39174000
ConditionNew
Artikel
FL-012105
Frequently Bought Together
-
This Item:
€8.23
-
Adjustable cutting ring fitting, thread M 22x1.5, tube stud 18 L, stainless steel 1.4571
€102.70
-
Push-in fitting, tee design, tube 12 mm, second port 10 mm, PVDF
€34.05
Total price
This push-in fitting is designed for a tube of 15 mm outside diameter and the continuing line. The part accepts the tube without tools and holds it by the gripping claws. The material is POM, the size is fixed at tube diameter 15 mm. The elbow design turns the line by 90 degrees and saves installation length.
Benefits
- The change of direction by 90 degrees saves installation length ahead of the port
- Approvals to NSF and ANSI 51 as well as 61, DVGW-W270, KTW are documented for the materials
- The tube is pushed in without tools and released again over the release ring
- The size 15 is clearly assigned and stays available for reordering
- With tube diameter 15 mm the size is fixed, so no reworking of the line is required
Technical data
| Material | POM |
|---|---|
| Tube outside diameter | 15 mm |
| Design version | large design |
| Seal material | NBR |
| Media | lubricated and unlubricated compressed air, neutral gases, cold water |
| Material approvals | NSF and ANSI 51 as well as 61, DVGW-W270, KTW |
Applications
Pneumatic cylinders and valve terminals, control air lines inside the control cabinet, workshop distribution and service units, compressed air installation on machines and plants.
Standards and conformity
The following approvals are documented for the materials used: NSF and ANSI 51 as well as 61, DVGW-W270, KTW.
| Weight | 0.022000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | IQSL 150 |
| EAN | 4050571378646 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
