One drive should serve two circuits on the same power unit. The internal gear pump PGH5-3X/160RE11WE4 carries a through-drive for that, delivers up to 480 l/min at 210 bar and mounts on a 4-hole flange 160B4SW to ISO 3019-2.
Internal Gear Pump PGH5-3X/160RE11WE4 - Bosch Rexroth R901412925
BOSCH REXROTH
Original product
Net price (excl. VAT)
€6,388.53
Item
BRR-R901412925
Manufacturer no.
R901412925
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901412925
Country of originGermany
ConditionNew
Artikel
BRR-R901412925
Frequently Bought Together
-
This Item:
€6,388.53
-
Internal Gear Pump PGF2-2X/016LL20VM - Bosch Rexroth R900983463
€877.87
-
Internal Gear Pump PGH5-3X/100RR11WU2 - Bosch Rexroth R901296759
€5,492.52
Total price
When a second pump has to sit behind the main one, the through-drive decides the layout. The internal gear pump PGH5-3X/160RE11WE4 brings one from the factory, delivers up to 480 l/min as a fixed displacement pump and works to 210 bar operating pressure. The shaft is cylindrical with a fitting key.
Benefits
- Through-drive included, so a second pump can be flanged on directly.
- Flow up to 480 l/min in size 160 as a fixed displacement pump.
- Operating pressure to 210 bar, and to 145 bar with HFC fluid.
- Cylindrical shaft Ø 40 mm with fitting key to ISO 3019-2.
- 4-hole mounting flange 160B4SW to ISO 3019-2, clockwise rotation.
- 49.8 kg in weight, cast iron housing, NBR seals.
Technical data
| Direction of rotation | clockwise rotation |
| Operating pressure max. special fluids | 145 bar |
| Displacement type | constant |
| Max. flow | 480 l/min |
| Product family | PGH |
| Through-drive | with |
| Hydraulic fluid | HFC |
| Shaft end | Cylindrical Ø 40 mm with fitting key, ISO 3019-2 |
| Fastening | 4-hole mounting flange 160B4SW, ISO 3019-2 |
| Operating pressure, max. | 210 bar |
| Size | 160 |
| Seals | NBR |
| Mounting flange | 4-hole mounting flange 160B4SW according to ISO 3019-2 |
| Weight | 49.8 kg |
Applications
The pump feeds open-circuit power units where two consumer circuits run off one drive, for example in presses and test benches. Internal gearing keeps noise and pulsation low, which counts in halls with units running all shift. Its HFC release makes it usable in plants with fire-resistant fluid.
Manufacturer
Bosch Rexroth lists this pump under material number R901412925, product family PGH.
| Norm | ISO 3019-2 |
|---|---|
| Hersteller-Nr | R901412925 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 49.800000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
