The 160B4SW flange according to ISO 3019-2 is the interface of many bell housings. This internal gear pump in size 160 fits it, has a cylindrical 40 mm shaft with fitting key and delivers 480 l/min at up to 210 bar. Weight 52.62 kg.
Internal Gear Pump PGH5-3X/160RE11VE4 - Bosch Rexroth R901147126
BOSCH REXROTH
Original product
Net price (excl. VAT)
€6,274.59
Item
BRR-R901147126
Manufacturer no.
R901147126
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901147126
Country of originGermany
ConditionNew
Artikel
BRR-R901147126
Frequently Bought Together
-
This Item:
€6,274.59
-
Internal Gear Pump PGH2-2X/005LE07VU2 - Bosch Rexroth R900703725
€1,138.11
-
Internal Gear Pump PGF1-2X/5,0LL01VM - Bosch Rexroth R900051295
€664.25
Total price
If an existing bell housing is to stay in service, the pump is chosen by its flange. The PGH5-3X with a 4-hole 160B4SW flange according to ISO 3019-2 fits there and delivers 480 l/min at a maximum operating pressure of 210 bar.
Benefits
- 4-hole mounting flange 160B4SW according to ISO 3019-2
- Cylindrical shaft end 40 mm with fitting key according to ISO 3019-2
- 480 l/min flow from size 160 with constant displacement
- Maximum operating pressure 210 bar, 145 bar with special fluids
- For variable-speed drives, no load cycle limitation, with through-drive
- FKM seals, HLP hydraulic fluid, clockwise rotation, 52.62 kg
Technical data
| Direction of rotation | clockwise rotation |
| Operating pressure max. special fluids | 145 bar |
| Displacement type | constant |
| Max. flow | 480 l/min |
| Product family | PGH |
| Through-drive | with |
| Hydraulic fluid | HLP |
| Shaft end | Cylindrical Ø 40 mm with fitting key, ISO 3019-2 |
| Fastening | 4-hole mounting flange 160B4SW, ISO 3019-2 |
| Operating pressure, max. | 210 bar |
| Size | 160 |
| Seals | FKM |
| Mounting flange | 4-hole mounting flange 160B4SW according to ISO 3019-2 |
| Weight | 52.62 kg |
Applications
The pump is used in power units whose motor is already flanged to ISO 3019-2. The cylindrical shaft with fitting key can be joined with common couplings. A second stage can be added through the through-drive.
Manufacturer
Bosch Rexroth lists this item under material number R901147126.
| Norm | ISO 3019-2 |
|---|---|
| Hersteller-Nr | R901147126 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 52.614000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
