Foto folgt: Druckbegrenzungsventil DBW10A2-5X/315-6EG24N9K4V

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Pressure relief valve DBW10A2-5X/315-6EG24N9K4V solenoid actuation 24 V DC NG 10 subplate mounting - Bosch Rexroth R900958973

Bosch Rexroth ✓ Original product Brand new Made in Germany

The DBW10A2-5X/315-6EG24N9K4V limits circuit pressure to the set value, with the function switched by a 24 V DC solenoid. Up to 350 bar and 250 l/min, size NG 10, subplate mounting, FKM seals. Genuine Bosch Rexroth, material number R900958973, weight 4.5 kg.

Net
€1,454.47
excl. VAT
Item BRR-R900958973
Manufacturer no. R900958973
Save Compare
Question about this item
Datasheet (PDF) User manual 6 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The DBW10A2-5X/315-6EG24N9K4V (NG 10) makes pressure limitation in the hydraulic circuit electrically switchable, actuated by a 24 V DC solenoid. The DBW10A2-5X/315-6EG24N9K4V is rated for up to 250 l/min and 350 bar operating pressure. The manufacturer classes the DBW10A2-5X/315-6EG24N9K4V as an industrial hydraulic valve in the high performance range.

Benefits

  • Mounts on a subplate with ISO 6264-06-09 porting pattern, pipework stays untouched when changing the valve
  • Operating pressure up to 350 bar
  • Flow rate up to 250 l/min
  • 24 V DC solenoid, connected via connector, 3-pole (2 + PE) according to EN 175301-803
  • FKM seals (code letter V in the type)

Applications

Suitable as system pressure limitation or safety valve in the circuit, the DBW10A2-5X/315-6EG24N9K4V is designed for subplate mounting to porting pattern ISO 6264-06-09. Approved hydraulic fluids for the DBW10A2-5X/315-6EG24N9K4V: HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR. Genuine Bosch Rexroth part, material number R900958973.

Technical data

TypeDBW10A2-5X/315-6EG24N9K4V
Material numberR900958973
Product typePressure relief valve with solenoid actuation
SizeNG 10
Type of connectionSubplate mounting
Connection diagramISO 6264-06-09
Type of actuationwith solenoid actuation
Spool symbolA
Number of switching positions2
Number of ports2
Operating pressure max.350 bar
Max. flow250 l/min
SealsFKM
Hydraulic fluidHL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR
Supply voltage24 V DC
Electrical connectorConnector, 3-pole (2 + PE)
Electrical connectionConnector, 3-pole (2 + PE) according to EN 175301-803
Weight4.5 kg
ManufacturerBosch Rexroth
Hersteller-NrR900958973
GPSR HerstellerdatenBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
BauformPlattenaufbau
Seal materialFKM
FunctionDruckbegrenzung
Actuation typeElectrical
NormDIN EN 175301-803, ISO 6264
Operating voltage24 V DC
Betriebsdruck max [bar]350

Downloads

Datasheet

User Manual

Questions about this item

Any other question?

Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
