Pressure relief valve DBDS10P1X/25V subplate mounting NG 10 max. 25 bar FKM - Bosch Rexroth R900478124

Name: Pressure relief valve DBDS10P1X/25V subplate mounting NG 10 max. 25 bar FKM - Bosch Rexroth R900478124
Brand: Bosch Rexroth
SKU: BRR-R900478124
Price: 456.35 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

The Bosch Rexroth DBDS10P1X/25V keeps pressure below the set value, excess oil flows from P to T back to tank. Size NG 10, subplate mounting, 25 bar max. operating pressure at up to 120 l/min, FKM seals. Genuine Bosch Rexroth part, material number R900478124, weight 3.64 kg.

Net

€456.35

excl. VAT

Item BRR-R900478124

Manufacturer no. R900478124

Question about this item

Datasheet (PDF) User manual 12 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The DBDS10P1X/25V pressure relief valve in size NG 10 protects pumps, lines and consumers against excessive pressure. It is rated for up to 25 bar operating pressure at a maximum of 120 l/min.

Benefits

Subplate mounting NG10: replace the valve without disconnecting the pipework
Rated for 25 bar max. operating pressure
Handles up to 120 l/min
Relief from P to T keeps the circuit below the set pressure
Mechanically actuated, no electrical connection needed
FKM seals

Applications

Typical use is protecting pumps and sub-circuits, here with subplate mounting. Original Bosch Rexroth product, material number R900478124.

Technical data

Type	DBDS10P1X/25V
Material number	R900478124
Product type	Pressure relief valve
Size	NG 10
Type of connection	Subplate mounting
Connection diagram	Subplate mounting NG10
Type of actuation	with mechanical actuation
Spool symbol	P to T
Number of switching positions	2
Number of ports	2
Operating pressure max.	25 bar
Max. flow	120 l/min
Seals	FKM
Hydraulic fluid	HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU (glycol + ester base), HFDR
Weight	3.64 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R900478124
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Ausführung	Plattenaufbau NG10
Bauform	Plattenaufbau
Seal material	FKM
Function	Druckbegrenzung
Actuation type	Mechanical
Betriebsdruck max [bar]	25
