Logic Cover LFA63EWA-7X/CA40DQMG24 - Bosch Rexroth R900956114

Without feedback, a sequence control has nothing but elapsed time to go by. The LFA63EWA-7X/CA40DQMG24 logic cover carries spool position monitoring and controls a 2-way cartridge valve for up to 5000 l/min.

Benefits

• Spool position monitoring, the next step is released on feedback rather than on a timer.
• Up to 5000 l/min in size 63 through the cartridge.
• 420 bar maximum operating pressure at 42.5 kg.
• 2 switching positions on 2 ports, flow A to B and B to A.
• Cavity to ISO 7368, driven at 24 VDC.

Technical data

Applications

The cover belongs in plants whose cycle consists of interlinked steps and where a wrong switch becomes expensive. That includes forming presses, forging plants and test rigs moving large flows. Position feedback can be tied into the sequence control and evaluated there.

Manufacturer

Bosch Rexroth, material number R900956114. HL hydraulic fluid and NBR seals in size 63 are what the cover is built for.
