Logic Cartridge Valve LC2A063B40F-1X/Z2Q7G24F - Bosch Rexroth R901407142

The standardised cavity decides whether an element fits an existing manifold. The logic cartridge valve LC2A063B40F-1X/Z2Q7G24F sits in the ISO 7368-12-11-1-16 cavity of size 63, switches up to 6000 l/min and works to 450 bar. The control cover of the Z2Q7G24F version weighs 29.04 kg.

Benefits

• Cavity ISO 7368-12-11-1-16, so it fits existing size 63 manifolds.
• Flow up to 6000 l/min across two ports.
• Operating pressure to 450 bar with FKM seals and HL hydraulic fluid.
• Two switching positions with hydraulic actuation, spool symbol A to B, B to A.
• 29.04 kg in weight in the Z2Q7G24F version.

Technical data

Applications

Elements like this sit in the main circuits of forging presses, injection moulding machines and hydro turbine controls. Because the cavity is standardised, the control cover can be swapped without touching the drilling pattern in the manifold. That shortens downtime during a conversion.

Manufacturer

Bosch Rexroth lists this cartridge valve under material number R901407142, product family LC2A.
