Push-in T-fitting with male thread M5 for tubing O.D. 3/16" QBT-M5-3/16-U-M - Festo 533249

Festo ✓ Original product Brand new

The push-in T-fitting QBT-M5-3/16-U-M screws into the threaded port via male thread M5, the other side takes tubing with O.D. 3/16". The housing is made of PBT, the nominal width is 2.997 mm and the permitted operating pressure max. 10 bar. Suitable for ambient temperatures of 0 to 60 °C.

Net
€3.76
excl. VAT
Item FES-533249
Manufacturer no. QBT-M5-3/16-U-M
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The push-in T-fitting QBT-M5-3/16-U-M screws into the threaded port via male thread M5, the other side takes tubing with O. D. 3/16". Nominal width 2.997 mm, operating pressure max. 10 bar.

Benefits

  • Male thread M5 with sealing ring on the screw-in stud
  • Connection for tubing O. D. 3/16"
  • Nominal width 2.997 mm
  • Operating pressure max. 10 bar
  • Housing in PBT, corrosion resistance class 1
  • Ambient temperature 0 to 60 °C

Applications

Application example QBT-M5-3/16-U-M: compressed air connection via male thread M5 on machines whose lines are in inch sizes (O. D. 3/16").

Technical data

FeatureValue
TypeQBT-M5-3/16-U-M
Festo part number533249
Sizestandard
Nominal width2.997 mm
Seal type on screw-in studsealing ring
DesignT-shape
Operating pressure, full temperature rangemax. 10 bar
Maritime classificationsee certificate
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumlubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Nominal tightening torque0.5 Nm
Tolerance of nominal tightening torque± 10 %
Product weight11.907 g
Mounting typeexternal hex A/F 10
Pneumatic connection 1male thread M5
Pneumatic connection 2for tubing O. D. 3/16"
Release ring colourgrey
Material noteRoHS compliant
Housing materialPBT
Thread seal materialNBR
Release ring materialPOM
Tubing clamp segment materialhigh-alloy stainless steel
ManufacturerFesto
Hersteller-NrQBT-M5-3/16-U-M
EAN4052568340742
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
ThreadM5
Seal materialNBR
MediumCompressed air
Thread typeExternal thread
Schlüsselweite [mm]10
Betriebsdruck max [bar]10
Pneumatic connectionM5
Temperaturbereich0-60 °C
Temperature (max.)60
