Push-in L-connector with plug sleeve Ø 5/16" for tubing O.D. 1/4" QSL-5/16H-1/4-U - Festo 153657

Festo ✓ Original product Brand new

The Festo push-in L-connector QSL-5/16H-1/4-U plugs into an existing push-in port with its plug sleeve Ø 5/16" and feeds one tube at 90° with O.D. 1/4". With -0.95 to 10 bar operating pressure it also suits vacuum lines, permitted ambient temperature is -10 to 60 °C.

Net
€3.88
excl. VAT
Item FES-153657
Manufacturer no. QSL-5/16H-1/4-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo push-in L-connector QSL-5/16H-1/4-U plugs into an existing push-in port with its plug sleeve Ø 5/16" and feeds one tube at 90° with O. D. 1/4". Following the push-pull principle, the tube (1/4") is simply pushed in and released again via the grey release ring.

Benefits

  • Pressure and vacuum -0.95 to 10 bar, so also suitable for vacuum
  • Temperature range permitted from -10 to 60 °C
  • Flow free cross-section with nominal size 3.5 mm
  • Grip and sealing clamping segment in high-alloy stainless steel, tubing seal in NBR
  • PWIS PWIS conformity VDMA24364-B1/B2-L, relevant for paint shops

Applications

Where there is little room next to the port, the elbow leads the tubing (tubing O. D. 1/4") away without kinking. Designed for compressed air to ISO 8573-1:2010 [7:-:-] at 3.5 mm nominal size. Lubricated operation is possible. Housing in PBT, RoHS compliant.

Technical data

FeatureValue
TypeQSL-5/16H-1/4-U
Festo part number153657
SizeStandard
Nominal size3.5 mm
Mounting positionAny
DesignL-shape
ConstructionPush-pull principle
Operating pressure complete temperature range-0.95 to 10 bar
Maritime classificationSee certificate
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Ambient temperature-10 to 60 °C
Product weight5.1 g
Pneumatic connection, port 1Push-in sleeve Ø 5/16"
Pneumatic connection, port 2For tubing outside diameter of 1/4"
Colour of release ringGrey
Note on materialsRoHS compliant
Material housingPBT
Material release ringPOM
Material tubing sealNBR
Material tubing clamp componentHigh-alloy stainless steel
Weight0.005 kg
ManufacturerFesto
Hersteller-NrQSL-5/16H-1/4-U
EAN4052568310448
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
BauformL-Form
Nominal size DN [mm]3,5
Size BGStandard
Seal materialNBR
MediumCompressed air
SeriesQSL
Betriebsdruck max [bar]10
Temperaturbereich-10-60 °C
Temperature (max.)60
