Push-in T-connector for tubing OD 5/16", PBT QBT-5/16T-U - Festo 564769

Festo ✓ Original product Brand new

With the push-in T-connector QBT-5/16T-U, one tubing line with an OD of 5/16" supplies two consumers. The QBT-5/16T-U is rated for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature. The tube is pushed in and released again via the release ring.

Net
€4.37
excl. VAT
Item FES-564769
Manufacturer no. QBT-5/16T-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With the push-in T-connector QBT-5/16T-U, one tubing line with an OD of 5/16" supplies two consumers. The QBT-5/16T-U is rated for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature.

Benefits

  • From vacuum up to 10 bar operating pressure -0.95 to 10 bar across the full temperature range
  • Housing made of PBTcorrosion resistance class CRC 1
  • Tubing seal made of NBR
  • LABS (PWIS) conformity to VDMA24364 zone III
  • Nominal width 6.502 mm
  • Ambient temperature 0 to 60 °C

Applications

QBT-5/16T-U is used where one line supplies several consumers. The QBT-5/16T-U works with compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible..

Technical data

FeatureValue
TypeQBT-5/16T-U
Festo part number564769
SizeStandard
Nominal width6.502 mm
Mounting positionAny
DesignT-shape
ConstructionPush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Product weight13.098 g
Pneumatic connection 1For tubing OD 5/16"
Pneumatic connection 2For tubing OD 5/16"
Release ring colourGrey
Material noteRoHS compliant
Housing materialPBT
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialHigh-alloy stainless steel
Weight0.012 kg
ManufacturerFesto
Hersteller-NrQBT-5/16T-U
EAN4052568366544
Zolltarifnummer39174000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
BauformT-Form
Size BGStandard
Seal materialNBR
MediumCompressed air
Betriebsdruck max [bar]10
Temperaturbereich0-60 °C
Temperature (max.)60
