Push-in L-fitting with male thread 10-32 UNF-2A for tubing O.D. 5/32" QBL-10-32-UNF-5/32-U - Festo 533286

Festo ✓ Original product Brand new

The push-in L-fitting QBL-10-32-UNF-5/32-U screws into the threaded port via male thread 10-32 UNF-2A, the other side takes tubing with O.D. 5/32". The housing is made of PBT, the nominal width is 2.489 mm and the permitted operating pressure -0.95 to 10 bar (vacuum included). RoHS compliant.

Net
€2.81
excl. VAT
Item FES-533286
Manufacturer no. QBL-10-32-UNF-5/32-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The push-in L-fitting QBL-10-32-UNF-5/32-U screws into the threaded port via male thread 10-32 UNF-2A, the other side takes tubing with O. D. 5/32". Nominal width 2.489 mm, operating pressure -0.95 to 10 bar.

Benefits

  • Male thread 10-32 UNF-2A with sealing ring on the screw-in stud
  • Connection for tubing O. D. 5/32"
  • Nominal width 2.489 mm
  • Operating pressure -0.95 to 10 bar, vacuum included
  • Housing in PBT, corrosion resistance class 1
  • Tubing released by the push-pull principle via the release ring

Applications

Application example QBL-10-32-UNF-5/32-U: compressed air connection via male thread 10-32 UNF-2A on machines whose lines are in inch sizes (O. D. 5/32").

Technical data

FeatureValue
TypeQBL-10-32-UNF-5/32-U
Festo part number533286
Sizestandard
Nominal width2.489 mm
Seal type on screw-in studsealing ring
Mounting positionany
DesignL-shape
Constructionpush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumlubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Max. tightening torque1.5 Nm
Product weight7.796 g
Mounting typeexternal hex 7/16
Pneumatic connection 1male thread 10-32 UNF-2A
Pneumatic connection 2for tubing O. D. 5/32"
Release ring colourgrey
Material noteRoHS compliant
Housing materialPBT
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialhigh-alloy stainless steel
Weight0.009 kg
ManufacturerFesto
Hersteller-NrQBL-10-32-UNF-5/32-U
EAN4052568341114
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
ThreadUNF 10-32
Seal materialNBR
MediumCompressed air
Thread typeExternal thread
Betriebsdruck max [bar]10
Temperaturbereich0-60 °C
Temperature (max.)60
