Push-in T-fitting with male thread 3/8 NPT for tubing O.D. 1/4" QBT-3/8-1/4-U - Festo 533317

Festo ✓ Original product Brand new

The push-in T-fitting QBT-3/8-1/4-U combines male thread 3/8 NPT with a connection for tubing O. D. 1/4". Made of PBT, nominal width 4.496 mm, rated for -0.95 to 10 bar operating pressure. Suitable for ambient temperatures of 0 to 60 °C. CRC 1, low corrosion stress. price per piece.

Net
€5.40
excl. VAT
Item FES-533317
Manufacturer no. QBT-3/8-1/4-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The push-in T-fitting QBT-3/8-1/4-U combines male thread 3/8 NPT with a connection for tubing O. D. 1/4". The nominal width is 4.496 mm and the operating pressure -0.95 to 10 bar.

Benefits

  • Male thread 3/8 NPT with sealing coating
  • Connection for tubing O. D. 1/4"
  • Nominal width 4.496 mm
  • Operating pressure -0.95 to 10 bar, vacuum included
  • Housing in PBT, corrosion resistance class 1
  • Tubing released by the push-pull principle via the release ring

Applications

The QBT-3/8-1/4-U suits systems with inch tubing (O. D. 1/4") and connects via male thread 3/8 NPT to valves, cylinders or service units.

Technical data

FeatureValue
TypeQBT-3/8-1/4-U
Festo part number533317
Sizestandard
Nominal width4.496 mm
Seal type on screw-in studcoating
Mounting positionany
DesignT-shape
Constructionpush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumlubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Product weight42.412 g
Mounting typeexternal hex 11/16
Pneumatic connection 1male thread 3/8 NPT
Pneumatic connection 2for tubing O. D. 1/4"
Release ring colourgrey
Material noteRoHS compliant
Housing materialPBT
Thread seal materialPTFE
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialhigh-alloy stainless steel
Weight0.028 kg
ManufacturerFesto
Hersteller-NrQBT-3/8-1/4-U
EAN4052568341428
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
ThreadNPT 3/8
Seal materialNBR, PTFE
MediumCompressed air
Thread typeExternal thread
Betriebsdruck max [bar]10
Pneumatic connectionNPT 3/8
Temperaturbereich0-60 °C
Temperature (max.)60
