Push-in Y-connector for tubing OD 8 mm, PBT NPQE-Y-Q8-E-F1A-P10 - Festo 8158806

Festo ✓ Original product Brand new

With the push-in Y-connector NPQE-Y-Q8-E-F1A-P10, two outlets branch off one tubing line with an OD of 8 mm. Operating pressure -0.95 to 8 bar, ambient -5 to 60 °C. The housing is made of PBT, corrosion resistance class CRC 1.

Net
€7.23
excl. VAT
Item FES-8158806
Manufacturer no. NPQE-Y-Q8-E-F1A-P10
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With the push-in Y-connector NPQE-Y-Q8-E-F1A-P10, two outlets branch off one tubing line with an OD of 8 mm. Operating pressure -0.95 to 8 bar, ambient -5 to 60 °C.

Benefits

  • From vacuum up to 8 bar operating pressure -0.95 to 8 bar across the full temperature range
  • LABS (PWIS) conformity to VDMA24364 zone III
  • Cleanroom suitable class 4 to ISO 14644-1
  • Battery production reduced Cu/Zn/Ni content to F1a
  • Nominal width 8.2 mm
  • Ambient temperature -5 to 60 °C

Applications

NPQE-Y-Q8-E-F1A-P10 is used where one line supplies several consumers. Approved medium for the NPQE-Y-Q8-E-F1A-P10: compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible..

Technical data

FeatureValue
TypeNPQE-Y-Q8-E-F1A-P10
Festo part number8158806
SizeStandard
Nominal width8.2 mm
Mounting positionAny
DesignY-shape
ConstructionPush-pull principle
Operating pressure, full temperature range-0.95 to 8 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Suitability for Li-ion battery productionSuitable for battery production with reduced Cu/Zn/Ni content (F1a)
Cleanroom suitability, measured to ISO 14644-14Class 4 to ISO 14644-1
Ambient temperature-5 to 60 °C
Product weight8 g
Pneumatic connection 1For tubing OD 8 mm
Pneumatic connection 2For tubing OD 8 mm
Release ring colourBlue
Material noteRoHS compliant
Housing materialPBT
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialHigh-alloy stainless steel
Weight0.008 kg
ManufacturerFesto
Hersteller-NrNPQE-Y-Q8-E-F1A-P10
EAN4052568599324
Zolltarifnummer39174000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
BauformY-Form
For hose OD [mm]8
Nominal size DN [mm]8,2
Size BGStandard
Seal materialNBR
MediumCompressed air
Betriebsdruck max [bar]8
Temperaturbereich-5-60 °C
Temperature (max.)60
