Push-in T-fitting with male thread 1/4 NPT for tubing O.D. 3/8" QBT-1/4-3/8-U - Festo 533316

Festo ✓ Original product Brand new

The push-in T-fitting QBT-1/4-3/8-U combines male thread 1/4 NPT with a connection for tubing O.D. 3/8". The housing is made of PBT, the nominal width is 8.001 mm and the permitted operating pressure -0.95 to 10 bar (vacuum included). Permitted ambient temperature: 0 to 60 °C. RoHS compliant.

Net
€6.81
excl. VAT
Item FES-533316
Manufacturer no. QBT-1/4-3/8-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The push-in T-fitting QBT-1/4-3/8-U combines male thread 1/4 NPT with a connection for tubing O. D. 3/8". Nominal width 8.001 mm, operating pressure -0.95 to 10 bar.

Benefits

  • Male thread 1/4 NPT with sealing coating
  • Connection for tubing O. D. 3/8"
  • Nominal width 8.001 mm
  • Operating pressure -0.95 to 10 bar, vacuum included
  • Housing in PBT, corrosion resistance class 1
  • Tubing released by the push-pull principle via the release ring

Applications

The QBT-1/4-3/8-U is suitable for working and control lines with O. D. 3/8", connected via male thread 1/4 NPT.

Technical data

FeatureValue
TypeQBT-1/4-3/8-U
Festo part number533316
Sizestandard
Nominal width8.001 mm
Seal type on screw-in studcoating
Mounting positionany
DesignT-shape
Constructionpush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumlubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Product weight38.386 g
Mounting typeexternal hex 11/16
Pneumatic connection 1male thread 1/4 NPT
Pneumatic connection 2for tubing O. D. 3/8"
Release ring colourgrey
Material noteRoHS compliant
Housing materialPBT
Thread seal materialPTFE
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialhigh-alloy stainless steel
Weight0.034 kg
ManufacturerFesto
Hersteller-NrQBT-1/4-3/8-U
EAN4052568341411
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
ThreadNPT 1/4
Seal materialNBR, PTFE
MediumCompressed air
Thread typeExternal thread
Betriebsdruck max [bar]10
Pneumatic connectionNPT 1/4
Temperaturbereich0-60 °C
Temperature (max.)60
