Push-in L-fitting female thread 1/4 NPT for tubing outside diameter of 1/4" QBLF-1/4-1/4-U - Festo 564659

Festo ✓ Original product Brand new

The Festo push-in L-fitting QBLF-1/4-1/4-U turns the tubing through 90° directly at the threaded port. Technically decisive: port 1 female thread 1/4 NPT and port 2 for tubing outside diameter of 1/4". Further: operating pressure -0.95 to 10 bar.

Net
€4.01
excl. VAT
Item FES-564659
Manufacturer no. QBLF-1/4-1/4-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo push-in L-fitting QBLF-1/4-1/4-U turns the tubing through 90° directly at the threaded port. Technically decisive: port 1 female thread 1/4 NPT and port 2 for tubing outside diameter of 1/4".

Benefits

  • Temperature range: usable from 0 to 60 °C
  • Pressure and vacuum: -0.95 to 10 bar, so also suitable for vacuum lines
  • Corrosion protection: corrosion resistance class CRC 1 (low corrosion stress)
  • Flow: nominal size 3.988 mm
  • PWIS: PWIS conformity VDMA24364 zone III

Applications

Suited to compressed air installations in machine building, especially with inch threads and inch tubing. Lubricated operation is possible. The permitted temperature range is 0 to 60 °C.

Technical data

FeatureValue
TypeQBLF-1/4-1/4-U
Festo part number564659
SizeStandard
Nominal size3.988 mm
Type of seal on screwed plugCoating
Mounting positionAny
DesignL-shape
ConstructionPush-pull principle
Operating pressure complete temperature range-0.95 to 10 bar
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Product weight22.708 g
Type of mountingExternal hex 11/16
Pneumatic connection, port 1Female thread 1/4 NPT
Pneumatic connection, port 2For tubing outside diameter of 1/4"
Colour of release ringGrey
Note on materialsRoHS compliant
Material housingPBT
Material thread sealPTFE
Material release ringPOM
Material tubing sealNBR
Material tubing clamp componentHigh-alloy stainless steel
Weight0.025 kg
ManufacturerFesto
Hersteller-NrQBLF-1/4-1/4-U
EAN4052568365455
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPBT
BauformL-Form
ThreadNPT 1/4 IG
Seal materialNBR
MediumCompressed air
Betriebsdruck max [bar]10
Temperaturbereich0-60 °C
Temperature (max.)60
