Spiral plastic tubing PU 6 x 4 mm working length 1 m black PUN-6X1-S-1-SW - Festo 197605

Festo ✓ Original product Brand new

Spiral tubing with 1 m working length for moving consumers, block length is just 0.344 m. Operating pressure -0.95 to 10 bar and ambient -35 to 60 °C.

Net
€11.51
excl. VAT
Item FES-197605
Manufacturer no. PUN-6X1-S-1-SW
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The spiral plastic tubing PUN-6X1-S-1-SW supplies moving consumers over a working length of 1 m and returns to its starting position by itself after extension.

Benefits

  • Operating pressure -0.95 to 10 bar (temperature-dependent)
  • Working length 1 m with 0.344 m block length and 23 turns
  • Shore hardness D 52 ± 3
  • Ambient temperature -35 to 60 °C
  • Approval TÜV

Applications

Operating medium compressed air to ISO 8573-1:2010 [7:-:-]. Typical on hand tools and blow guns.

Technical data

FeatureValue
TypePUN-6X1-S-1-SW
Festo part number197605
Working length1 m
Outside diameter6 mm
Block length0.344 m
Inside diameter4 mm
Winding diameter46 mm
Number of turns23
Temperature-dependent operating pressure-0.95 to 10 bar
ApprovalTÜV
Certificate issuing authorityB 013277 0527 00
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
LABS (PWIS) conformityVDMA24364-B2-L
Ambient temperature-35 to 60 °C
ColourBlack
Shore hardnessD 52 ± 3
Material tubingTPE-U(PU)
Weight (price list)0.075 kg
Weight0.075 kg
ManufacturerFesto
Hersteller-NrPUN-6X1-S-1-SW
EAN4052568045494
Zolltarifnummer39173200
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Farbeschwarz
MaterialPolyurethan
MediumCompressed air
Schlauchdurchmesser (außen) [mm]6
Schlauchdurchmesser (außen x innen) [mm]6 x 4
Schlauchdurchmesser (innen) [mm]4
Betriebsdruck max [bar]10
Temperaturbereich-35-60 °C
