Plastic tubing PTFEN-6X1-NT-500 - Festo 8061178
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Outside diameter | 6 mm |
|---|---|
| Flow-relevant bending radius | 40 mm |
| Inside diameter | 4 mm |
| Min. bending radius | 38 mm |
| Instructions on use | Tubing without printing |
| Operating pressure complete temperature range | -0.95 ... 5 bar |
| Temperature-dependent operating pressure | -0.95 ... 15 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Fire test material | UL94 V-0 |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Element installed statically, no meaningful evaluation possible according to ISO 14644-1 |
| Suitable for use with food | See supplementary material information |
| Ambient temperature | -20 ... 150 °C |
| Product weight according to length | 0.034 kg/m |
| Pneumatic connection | For push-in connector O.D. 6 mm, For barbed fitting outside diameter of 6 mm with union nut, For barbed fitting I.D. 4 mm with union nut, For barbed fitting I.D. 4 mm |
| Colour | Natural |
| Shore hardness | D 55 +/-5 |
| Note on materials | RoHS compliant |
| Material tubing | PTFE |
| Weight | 0.05 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PTFEN-6X1-NT-500 |
| EAN | 4052568290672 |
| Zolltarifnummer | 39173200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
