Straight push-in fitting 1/4 NPT to tubing OD 1/2", nickel-plated brass QB-1/4-1/2-U - Festo 567771

Festo ✓ Original product Brand new

With the QB-1/4-1/2-U push-in fitting, tubing with an OD of 1/2" is connected to a 1/4 NPT thread without tools. The QB-1/4-1/2-U is specified for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature.

Net
€2.83
excl. VAT
Item FES-567771
Manufacturer no. QB-1/4-1/2-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With the QB-1/4-1/2-U push-in fitting, tubing with an OD of 1/2" is connected to a 1/4 NPT thread without tools. The QB-1/4-1/2-U is specified for -0.95 to 10 bar operating pressure and 0 to 60 °C ambient temperature.

Benefits

  • From vacuum up to 10 bar operating pressure -0.95 to 10 bar across the full temperature range
  • Nominal width 6.401 mm
  • Ambient temperature 0 to 60 °C
  • Push-pull principle push the tube in, press the grey release ring to remove it
  • Housing made of nickel-plated brasscorrosion resistance class CRC 1
  • Tubing seal made of NBR

Applications

The QB-1/4-1/2-U connects tubing lines to valves, actuators and manifolds with a 1/4 NPT thread. The QB-1/4-1/2-U works with compressed air to ISO 8573-1:2010 [7:-:-], lubricated operation possible..

Technical data

FeatureValue
TypeQB-1/4-1/2-U
Festo part number567771
SizeStandard
Nominal width6.401 mm
Seal type on screw-in studCoating
Mounting positionAny
DesignStraight
ConstructionPush-pull principle
Operating pressure, full temperature range-0.95 to 10 bar
Operating mediumcompressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot mediumLubricated operation possible
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Ambient temperature0 to 60 °C
Product weight35.097 g
Mounting typeExternal hex 7/8, internal hex 1/4
Pneumatic connection 1Male thread 1/4 NPT
Pneumatic connection 2For tubing OD 1/2"
Release ring colourGrey
Material noteRoHS compliant
Housing materialNickel-plated brass
Thread seal materialPTFE
Release ring materialPOM
Tubing seal materialNBR
Tubing clamp segment materialHigh-alloy stainless steel
Weight0.045 kg
ManufacturerFesto
Hersteller-NrQB-1/4-1/2-U
EAN4052568369910
Zolltarifnummer74122000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialNickel-plated brass
Bauformgerade Form
ThreadNPT 1/4
Size BGStandard
Seal materialNBR
MediumCompressed air
Thread typeExternal thread
Betriebsdruck max [bar]10
Temperaturbereich0-60 °C
Temperature (max.)60
