Push-in fitting in nickel-plated brass with male thread 1/2 NPT for tubing O.D. 3/8" QB-1/2-3/8-U - Festo 533283
The push-in fitting QB-1/2-3/8-U combines male thread 1/2 NPT with a connection for tubing O.D. 3/8". Made of nickel-plated brass, nominal width 8.001 mm, rated for -0.95 to 10 bar operating pressure. Suitable for ambient temperatures of 0 to 60 °C. CRC 1, low corrosion stress. RoHS compliant.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The push-in fitting QB-1/2-3/8-U combines male thread 1/2 NPT with a connection for tubing O. D. 3/8". The nominal width is 8.001 mm and the operating pressure -0.95 to 10 bar.
Benefits
- Male thread 1/2 NPT with sealing coating
- Connection for tubing O. D. 3/8"
- Nominal width 8.001 mm
- Operating pressure -0.95 to 10 bar, vacuum included
- Housing in nickel-plated brass, corrosion resistance class 1
- Tubing released by the push-pull principle via the release ring
Applications
The QB-1/2-3/8-U is suitable for working and control lines with O. D. 3/8", connected via male thread 1/2 NPT.
Technical data
| Feature | Value |
|---|---|
| Type | QB-1/2-3/8-U |
| Festo part number | 533283 |
| Size | standard |
| Nominal width | 8.001 mm |
| Seal type on screw-in stud | coating |
| Mounting position | any |
| Design | straight |
| Construction | push-pull principle |
| Operating pressure, full temperature range | -0.95 to 10 bar |
| Operating medium | compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | lubricated operation possible |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | 0 to 60 °C |
| Product weight | 50.406 g |
| Mounting type | external hex 7/8, internal hex 5/16 |
| Pneumatic connection 1 | male thread 1/2 NPT |
| Pneumatic connection 2 | for tubing O. D. 3/8" |
| Release ring colour | grey |
| Material note | RoHS compliant |
| Housing material | nickel-plated brass |
| Thread seal material | PTFE |
| Release ring material | POM |
| Tubing seal material | NBR |
| Tubing clamp segment material | high-alloy stainless steel |
| Weight | 0.047 kg |
| Manufacturer | Festo |
| Hersteller-Nr | QB-1/2-3/8-U |
| EAN | 4052568341084 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Nickel-plated brass |
| Thread | NPT 1/2 |
| Seal material | NBR, PTFE |
| Medium | Compressed air |
| Thread type | External thread |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | NPT 1/2 |
| Temperaturbereich | 0-60 °C |
| Temperature (max.) | 60 |
