Spiral plastic tubing PA12 7.8 x 6.2 mm working length 15 m blue PPS-6-15-1/4-BL - Festo 19797
Spiral tubing with 15 m working length for moving consumers, block length is just 0.8 m. Operating pressure -0.95 to 17.2 bar and ambient -30 to 80 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The spiral plastic tubing PPS-6-15-1/4-BL supplies moving consumers over a working length of 15 m and returns to its starting position by itself after extension. Connection: Male thread G1/4.
Benefits
- Operating pressure -0.95 to 17.2 bar (temperature-dependent)
- Working length 15 m with 0.8 m block length and 86 turns
- Ambient temperature -30 to 80 °C
Applications
Permitted media: compressed air to ISO 8573-1:2010 [7:-:-]. Typical on hand tools and blow guns.
Technical data
| Feature | Value |
|---|---|
| Type | PPS-6-15-1/4-BL |
| Festo part number | 19797 |
| Working length | 15 m |
| Outside diameter | 7.8 mm |
| Block length | 0.8 m |
| Inside diameter | 6.2 mm |
| Winding diameter | 75 mm |
| Number of turns | 86 |
| Temperature-dependent operating pressure | -0.95 to 17.2 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -30 to 80 °C |
| Nominal torque | 11 Nm |
| Tolerance for nominal tightening torque | ± 20 % |
| Pneumatic connection, port 1 | Male thread G1/4 |
| Pneumatic connection, port 2 | Male thread G1/4 |
| Colour | Blue |
| Material connecting thread | brass |
| Note on materials | RoHS compliant |
| Material buckling protection | Steel, Galvanised |
| Material tubing | PA12-P |
| Weight (price list) | 0.46 kg |
| Weight | 0.46 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PPS-6-15-1/4-BL |
| EAN | 4052568009496 |
| Zolltarifnummer | 39173300 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Farbe | blau |
| Material | PA 12 |
| Medium | Compressed air |
| Schlauchdurchmesser (außen) [mm] | 7,8 |
| Schlauchdurchmesser (außen x innen) [mm] | 7,8 x 6,2 |
| Schlauchdurchmesser (innen) [mm] | 6,2 |
| Betriebsdruck max [bar] | 17 |
| Temperaturbereich | -30-80 °C |
