PE plastic tubing, O.D. 16 mm, I.D. 10.8 mm, red PEN-16X2,5-RT - Festo 551479

Festo ✓ Original product Brand new

The plastic tubing PEN-16X2,5-RT made of polyethylene carries compressed air and water at operating pressures of -0.95 to 10 bar, O.D. 16 mm. I.D. 10.8 mm, min bending radius 57.5 mm and suitable for energy chains. Ambient temperature -30 to 60 °C, Shore hardness D 52 ±3 and TÜV approval.

Net
€2.78
excl. VAT
Item FES-551479
Manufacturer no. PEN-16X2,5-RT
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo plastic tubing PEN-16X2,5-RT made of polyethylene carries compressed air and water at operating pressures of -0.95 to 10 bar, O.D. 16 mm.

Benefits

  • Operating pressure -0.95 to 10 bar, compressed air and water
  • Min bending radius 57.5 mm, flow-relevant 122 mm
  • O.D. 16 mm, I.D. 10.8 mm
  • Suitable for energy chains, Shore hardness D 52 ±3
  • Colour red
  • Ambient temperature -30 to 60 °C, TÜV approval

Application

The tubing connects valves, drives and service units in compressed air systems. Suitable for push-in connector O.D. 16 mm.

Technical data

TypePEN-16X2,5-RT
Outside diameter16 mm
Flow-relevant bending radius122 mm
Inside diameter10.8 mm
Minimum bending radius57.5 mm
Tubing characteristicsSuitable for energy chains
Temperature-dependent operating pressure-0.95 to 10 bar
ApprovalTÜV
Certificate issuing authorityB 013277 0527 00
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-], water (liquid, ice-free)
LABS (PWIS) conformityVDMA24364-B2-L
Cleanroom suitability, measured according to ISO 14644-14Element installed statically, no meaningful evaluation possible according to ISO 14644-1
Ambient temperature-30 to 60 °C
Product weight according to length0.1029 kg/m
Pneumatic connectionFor push-in connector O.D. 16 mm
ColourRed
Shore hardnessD 52 ±3
Note on materialsRoHS compliant
Material tubingPE
Weight (price list)110 g
Weight0.11 kg
ManufacturerFesto
Hersteller-NrPEN-16X2,5-RT
EAN4052568052645
Zolltarifnummer39173200
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialPolyethylene
For hose OD [mm]16
MediumCompressed air, water
Schlauchdurchmesser (außen) [mm]16
Schlauchdurchmesser (innen) [mm]10,8
min. Biegeradius [mm]57,5
Betriebsdruck max [bar]10
Temperature (max.)60
