PE plastic tubing, O.D. 16 mm, I.D. 10.8 mm, green PEN-16X2,5-GN - Festo 551473
The plastic tubing PEN-16X2,5-GN made of polyethylene carries compressed air and water at operating pressures of -0.95 to 10 bar, O.D. 16 mm. I.D. 10.8 mm, min bending radius 57.5 mm and suitable for energy chains. Ambient temperature -30 to 60 °C, Shore hardness D 52 ±3 and TÜV approval.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo plastic tubing PEN-16X2,5-GN made of polyethylene carries compressed air and water at operating pressures of -0.95 to 10 bar, O.D. 16 mm.
Benefits
- Operating pressure -0.95 to 10 bar, compressed air and water
- Colour green
- Suitable for energy chains, Shore hardness D 52 ±3
- Ambient temperature -30 to 60 °C, TÜV approval
- O.D. 16 mm, I.D. 10.8 mm
- Min bending radius 57.5 mm, flow-relevant 122 mm
Application
The tubing connects valves, drives and service units in compressed air systems. Suitable for push-in connector O.D. 16 mm.
Technical data
| Type | PEN-16X2,5-GN |
|---|---|
| Outside diameter | 16 mm |
| Flow-relevant bending radius | 122 mm |
| Inside diameter | 10.8 mm |
| Minimum bending radius | 57.5 mm |
| Tubing characteristics | Suitable for energy chains |
| Temperature-dependent operating pressure | -0.95 to 10 bar |
| Approval | TÜV |
| Certificate issuing authority | B 013277 0527 00 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-], water (liquid, ice-free) |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Element installed statically, no meaningful evaluation possible according to ISO 14644-1 |
| Ambient temperature | -30 to 60 °C |
| Product weight according to length | 0.1029 kg/m |
| Pneumatic connection | For push-in connector O.D. 16 mm |
| Colour | Green |
| Shore hardness | D 52 ±3 |
| Note on materials | RoHS compliant |
| Material tubing | PE |
| Weight (price list) | 110 g |
| Weight | 0.11 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PEN-16X2,5-GN |
| EAN | 4052568052584 |
| Zolltarifnummer | 39173200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Polyethylene |
| For hose OD [mm] | 16 |
| Medium | Compressed air, water |
| Schlauchdurchmesser (außen) [mm] | 16 |
| Schlauchdurchmesser (innen) [mm] | 10,8 |
| min. Biegeradius [mm] | 57,5 |
| Betriebsdruck max [bar] | 10 |
| Temperature (max.) | 60 |
