Flanged pressure gauge 0 to 10 bar Ø 63 mm G1/4 class 2.5 PAGN-P-63-1M-G14 - Festo 8037000
The flanged pressure gauge PAGN-P-63-1M-G14 is designed to display pressure in the range 0 to 10 bar, connected via G1/4. Connection G1/4 (rear, centred), accuracy class 2.5, front panel mounting, double scale, MPa (outer scale), bar (inner scale), degree of protection IP43.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The flanged pressure gauge PAGN-P-63-1M-G14 is designed to display pressure in the range 0 to 10 bar, connected via G1/4.
Benefits
- Display range 0 to 10 bar, double scale, MPa (outer scale), bar (inner scale)
- Accuracy class 2.5 to EN 837-1
- Nominal size 63, front panel mounting
- Connection G1/4, stud made of brass
- Housing made of ABS, window made of SAN
- Ambient and medium temperature -20 to 60 °C
Applications
Measuring media for the PAGN-P-63-1M-G14: inert gases, neutral liquids, no acetylene, no oxygen. The PAGN-P-63-1M-G14 is intended for front panel mounting in control cabinets and operator panels. Alternating load factor 0.66.
Technical data
| Feature | Value |
|---|---|
| Display range | 0 to 10 bar |
| Conforms to standard | EN 837-1 |
| Nominal size of pressure gauge | 63 |
| Design | Bourdon tube pressure gauge |
| Type of mounting | Front panel mounting |
| Operating medium | Inert gases, neutral liquids |
| Note on operating and pilot medium | No acetylene, no oxygen |
| Operating pressure | 0 to 10 bar |
| Alternating load factor | 0.66 |
| Measurement accuracy class | 2.5 |
| Degree of protection | IP43 |
| Storage temperature | -40 to 70 °C |
| Media temperature | -20 to 60 °C |
| Ambient temperature | -20 to 60 °C |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Note on materials | RoHS compliant |
| Position of connection | Rear, centred |
| Pneumatic connection | G1/4 |
| Material in contact with the medium | Brass |
| Material screwed plug | Brass |
| Material housing | ABS |
| Material window | SAN |
| Material mounting ring | Steel |
| Material screws | Steel |
| Housing colour | Black |
| Scale | Double scale, MPa (outer scale), bar (inner scale) |
| Type | PAGN-P-63-1M-G14 |
| Festo part number | 8037000 |
| Weight (price list) | 320 g |
| Weight | 0.32 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PAGN-P-63-1M-G14 |
| EAN | 4052568430108 |
| Zolltarifnummer | 90262040 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Colour | Black |
| Thread | G 1/4 |
| Measuring range max. [bar] | 10 |
| Anzeigebereich [bar] | 0 bis 10 |
| Medientemperatur [°C] | -20 bis 60 |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP43 |
| Temperature (max.) | 60 |
