Vacuum generator with switch-on valve and vacuum switch Laval nozzle 2 mm vacuum 93 % OVEM-20-H-B-GO-CE-N-2P - Festo 593586

Festo ✓ Original product Brand new

The vacuum generator OVEM-20-H-B-GO-CE-N-2P generates vacuum from compressed air via a Laval nozzle with 2 mm nominal size. Integrated functions: vacuum switch and electric switch-on valve.

Net
€836.82
excl. VAT
Item FES-593586
Manufacturer no. OVEM-20-H-B-GO-CE-N-2P
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The vacuum generator OVEM-20-H-B-GO-CE-N-2P works with a 2 mm Laval nozzle. Ejector characteristic: high vacuum, Standard.

Benefits

  • Vacuum up to 93 %
  • Vacuum monitoring with integrated vacuum switch: switching output 2xPNP
  • Electrics: connection M12x1, Plug

Applications

The high vacuum suits dense, smooth workpieces such as sheet metal, glass or plastic panels.

Technical data

Nominal size, Laval nozzle2 mm
DesignModular
Ejector characteristicHigh vacuum, Standard
Maximum vacuum93 %
Operating pressure2 to 8 bar
Pneumatic connection, port 1G1/4
Vacuum connectionG1/4
Valve functionClosed
Integrated functionVacuum switch, Electric switch-on valve
Switching output2xPNP
Electrical connectionM12x1, Plug
Weight0.48 kg
ManufacturerFesto
Hersteller-NrOVEM-20-H-B-GO-CE-N-2P
Zolltarifnummer84141089
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/4
Nominal size DN [mm]2
Functionclosed
SeriesOVEM
Betriebsdruck max [bar]8
Pneumatic connectionG1/4
