Round flat vacuum suction cup Ø 30 mm NBR G3/8 OGVM-30-S-N-G38F - Festo 8211013

Festo ✓ Original product Brand new

The Festo OGVM-30-S-N-G38F vacuum suction cup grips workpieces securely with 36 N of holding force at -0.6 bar nominal operating pressure. Round flat design made of NBR. Low internal volume of 1.8 cm³ in a flat design, so the vacuum builds up quickly. NBR suction cup, Shore hardness 60 +/-5.

Net
€30.77
excl. VAT
Item FES-8211013
Manufacturer no. OGVM-30-S-N-G38F
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo OGVM-30-S-N-G38F vacuum suction cup grips workpieces securely with 36 N of holding force at -0.6 bar nominal operating pressure.

Why choose it

  • Holding force of 36 N at a nominal operating pressure of -0.6 bar
  • Low internal volume of 1.8 cm³ in a flat design, so the vacuum builds up quickly
  • NBR suction cup, Shore hardness 60 +/-5
  • Takes up 35 N of lateral force at nominal operating pressure
  • Vacuum connection female thread G3/8 on top, mounted directly via the port

Typical applications

Flat suction cups suit smooth, even workpieces such as sheet metal, glass, cardboard or plastic panels.

Technical data

TypeOGVM-30-S-N-G38F
Festo part number8211013
Height compensator for suction cup3 mm
Minimum workpiece radius35 mm
Nominal size4 mm
Suction cup diameter30 mm
Suction cup volume1.8 cm³
Position of connectionOn top
Mounting positionAny
Suction cup shapeRound, flat
Operating pressure-0.95 to 0 bar
Nominal operating pressure-0.6 bar
Operating mediumAtmospheric air based on ISO 8573-1:2010 [7:-:-]
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-A1/A2-L
Ambient temperature-20 to 80 °C
Holding force at nominal operating pressure36 N
Lateral force at nominal operating pressure35 N
Product weight21 g
Type of mountingVia vacuum port
Vacuum connectionFemale thread G3/8
ColourBlack
Shore hardness60 +/-5
Material screwed plugWrought aluminium alloy
Note on materialsRoHS compliant
Material suction cupNBR
Weight0.023 kg
ManufacturerFesto
Hersteller-NrOGVM-30-S-N-G38F
EAN4052568790301
Zolltarifnummer84799070
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialNBR
ThreadG 3/8 IG
Nominal size DN [mm]4
Diameter [mm]30
MediumAir
Thread typeInternal thread
Pneumatic connectionG3/8 IG
Temperaturbereich-20-80 °C
Temperature (max.)80
