Connecting cable 3 m, suitable for energy chains, 4x socket with connection pattern L15 to open end NEBM-L15G24-ES-3-LE24 - Festo 8178802
The 3 m connecting cable NEBM-L15G24-ES-3-LE24 runs from 4x socket with connection pattern L15 to open end. The cable is suitable for energy chains and allows a 33 mm bending radius in moving installation. The PUR sheath has a diameter of 3.3 to 4.6 mm. The cable sheath is made of PUR.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo connecting cable NEBM-L15G24-ES-3-LE24 is 3 m long and suitable for energy chains.
Benefits
- Field device side: 4x socket with connection pattern L15, straight, 24 pins
- Control side: open end, 24 cores, wire ferrule
- Suitable for energy chains: bending radius moving 33 mm, fixed 23.1 mm
- Cable sheath: PUR, diameter 3.3 to 4.6 mm, shielded
Applications
It belongs to the Festo accessories for servo drives. For moving axes in energy chains the 33 mm bending radius is decisive.
Technical data
| Cable designation | Without inscription label holder |
|---|---|
| Product weight | 210 g |
| Electrical connection 1, function | Field device side |
| Electrical connection 1, connection type | 4x socket |
| Electrical connection 1, cable outlet | Straight |
| Electrical connection 1, connector system | Connection pattern L15 |
| Electrical connection 1, number of connections/cores | 24 |
| Electrical connection 1, used connections/cores | 24 |
| Electrical connection 2, function | Control side |
| Electrical connection 2, connection type | 4x cable |
| Electrical connection 2, connector system | Open end |
| Electrical connection 2, number of connections/cores | 24 |
| Electrical connection 2, used connections/cores | 24 |
| Nominal operating voltage DC | 24 V |
| Shielding | Yes |
| Cable length | 3 m |
| Cable characteristic | Suitable for energy chains |
| Bending radius, fixed cable | 23.1 mm |
| Bending radius, moving cable | 33 mm |
| Cable diameter | 3.3 to 4.6 mm |
| Cable structure | 2 x 4 x 0.25 mm² + 2 x 8 x 0.08 mm² |
| Nominal cross section conductor | 0.08 to 0.25 mm² |
| Wire ends | Wire ferrule |
| Ambient temperature | -30 to 70 °C |
| Ambient temperature with moving cable | -5 to 70 °C |
| Storage temperature | -30 to 70 °C |
| Relative air humidity | 0 - 100% |
| Nominal altitude of use | ≤ 2000 m NHN |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK instructions for EMC |
| KC mark | KC-EMV |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Note on materials | RoHS compliant |
| Material cable sheath | PUR |
| Weight | 0.29 kg |
| Manufacturer | Festo |
| Hersteller-Nr | NEBM-L15G24-ES-3-LE24 |
| EAN | 4052568633370 |
| Zolltarifnummer | 85444290 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PUR |
| min. Biegeradius [mm] | 23,1 |
| Operating voltage | 24 V DC |
| Series | NEBM |
| Temperature (max.) | 70 |
