Connecting cable socket M12x1 8-pin to plug M12x1 8-pin 15 m NEBC-M12G8-E-15-N-M12G8 - Festo 8080785

Festo ✓ Original product Brand new

The Festo connecting cable NEBC-M12G8-E-15-N-M12G8 links field devices such as sensors or valves to the control side. At a glance: connectors socket M12x1, A-coded, 8-pin, straight and plug M12x1, A-coded, 8-pin, straight and cable length 15 m.

Net
€83.44
excl. VAT
Item FES-8080785
Manufacturer no. NEBC-M12G8-E-15-N-M12G8
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo connecting cable NEBC-M12G8-E-15-N-M12G8 links field devices such as sensors or valves to the control side. At a glance: connectors socket M12x1, A-coded, 8-pin, straight and plug M12x1, A-coded, 8-pin, straight and cable length 15 m.

Benefits

  • Ready to install: 15 m long, assembled at both ends
  • Moving applications: suitable for energy chains, bending radius 30 mm in motion
  • Sealed: degree of protection IP65, IP67, dust-tight, protected against temporary immersion
  • Temperature range: usable from -25 to 90 °C
  • Electrical: operating voltage 0 to 30 V DC, current rating 2 A at 40 °C
  • Corrosion protection: corrosion resistance class CRC 2 (moderate corrosion stress)

Applications

Intended for energy chains and moving machine parts. The permitted temperature range is -25 to 90 °C.

Technical data

FeatureValue
TypeNEBC-M12G8-E-15-N-M12G8
Festo part number8080785
Based on standardEN 61076-2-101
Approvalc UL us - Listed (Oil)
Cable designationWithout inscription label holder
Product weight736 g
Electrical connection 1, functionField device side
Electrical connection 1, designRound
Electrical connection 1, connection typeSocket
Electrical connection 1, cable outletStraight
Electrical connection 1, connector systemM12x1, A-coded to EN 61076-2-101
Electrical connection 1, number of connections/cores8
Electrical connection 1, used connections/cores8
Electrical connection 1, type of mountingScrew-type lock
Electrical connection 2, functionControl side
Electrical connection 2, designRound
Electrical connection 2, connection typePlug
Electrical connection 2, cable outletStraight
Electrical connection 2, connector systemM12x1, A-coded to EN 61076-2-101
Electrical connection 2, number of connections/cores8
Electrical connection 2, used connections/cores8
Electrical connection 2, type of mountingScrew-type lock
Operational voltage range DC0 to 30 V
Operational voltage range AC0 to 30 V
Current rating at 40° C2 A
Immunity to surge0.8 kV
ShieldingNo
Cable length15 m
Cable characteristicSuitable for energy chains
Test conditions cableTest conditions on request
Bending radius, fixed cable30 mm
Bending radius, moving cable30 mm
Cable diameter6 mm
Cable diameter tolerance±0.2 mm
Cable structure8 x 0.25 mm²
Nominal cross section conductor0.25 mm²
Degree of protectionIP65, IP67
Note on degree of protectionIn mounted state
Ambient temperature-25 to 90 °C
Ambient temperature with moving cable-25 to 90 °C
CE mark (see declaration of conformity)In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)To UK RoHS instructions
LABS (PWIS) conformityVDMA24364-B2-L
Note on materialsRoHS compliant
Pollution degree3
Corrosion resistance class CRC2 - Moderate corrosion stress
Material cable sheathTPE-U(PUR)
Cable sheath colourSilver-grey
Material housingTPE-U(PUR)
Housing colourBlack
Material screw-type lockNickel-plated die-cast zinc
Material sealsNBR
Material electrical contactBrass
Material insulating sheathPP
Weight0.75 kg
ManufacturerFesto
Hersteller-NrNEBC-M12G8-E-15-N-M12G8
EAN4052568456702
Zolltarifnummer85444290
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ColourBlack
MaterialTPE-U(PUR)
Seal materialNBR
Length [mm]15000
NormDIN EN 61076-2-101
SeriesNEBC
Protection ratingIP67
Temperature (max.)90
