Activated carbon filter residual oil 0.003 mg/m³ 1 NPT MS9-LFX-N1-U - Festo 553034
The activated carbon filter MS9-LFX-N1-U removes oil vapour from the compressed air and lowers the residual oil content to 0.003 mg/m³. Key values: port 1 NPT, operating pressure 0 to 20 bar and media temperature 5 to 30 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The key values of the activated carbon filter MS9-LFX-N1-U: residual oil content 0.003 mg/m³, 6500 l/min flow rate and port 1 NPT. The activated carbon filter MS9-LFX-N1-U removes oil vapour from the compressed air and lowers the residual oil content to 0.003 mg/m³.
Advantages
- Residual oil content at the outlet 0.003 mg/m³.
- Max. standard flow rate for clean air class 6500 l/min.
- Operating pressure 0 to 20 bar.
- Cleanroom suitability: class 7 according to ISO 14644-1.
- Pneumatic connection 1 NPT.
- Corrosion resistance class CRC 2, LABS (PWIS) conformity VDMA24364-B1/B2-L.
Application
The activated carbon filter MS9-LFX-N1-U is used as the last stage after a micro filter, for example in packaging, painting or measuring applications. For installation: mounting position vertical ±5° and operating medium compressed air according to ISO 8573-1:2010 [3:4:2].
Technical data
| Type | MS9-LFX-N1-U |
|---|---|
| Size | 9 |
| Series | MS |
| Mounting position | Vertical ±5° |
| Design | Activated carbon filter |
| Operating pressure | 0 to 20 bar |
| Max. standard flow rate for clean air class | 6500 l/min |
| Operating medium | Compressed air according to ISO 8573-1:2010 [3:4:2] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Class 7 according to ISO 14644-1 |
| Storage temperature | -10 to 60 °C |
| Air purity class at output | Compressed air according to ISO 8573-1:2010 [3:4:1] |
| Media temperature | 5 to 30 °C |
| Residual oil content | 0.003 mg/m³ |
| Ambient temperature | -10 to 60 °C |
| Product weight | 2000 g |
| Type of mounting | With accessories |
| Pneumatic connection, port 1 | 1 NPT |
| Pneumatic connection, port 2 | 1 NPT |
| Material covering | PA |
| Material seals | NBR |
| Material filter | Activated carbon |
| Material housing | Die-cast aluminium |
| Material bowl | Wrought aluminium alloy |
| Material screen | PA |
| Manufacturer | Festo |
| Hersteller-Nr | MS9-LFX-N1-U |
| EAN | 4052568358068 |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Seal material | NBR |
| Housing material | Die-cast aluminium |
| Medium | Compressed air |
| Betriebsdruck max [bar] | 20 |
| Temperature (max.) | 30 |
