Filter regulator 40 µm 0.5 to 7 bar MS9-LFR-NG-D6-EUV-DI-AG-PSI-AS - Festo 564125

Festo ✓ Original product Brand new

The filter regulator MS9-LFR-NG-D6-EUV-DI-AG-PSI-AS filters the compressed air with a 40 µm grade of filtration and keeps the output pressure constant within 0.5 to 7 bar. Key values: operating pressure 2 to 12 bar, condensate drain fully automatic and media temperature -10 to 60 °C.

Net
€344.39
excl. VAT
Item FES-564125
Manufacturer no. MS9-LFR-NG-D6-EUV-DI-AG-PSI-AS
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo filter regulator MS9-LFR-NG-D6-EUV-DI-AG-PSI-AS at a glance: grade of filtration 40 µm, pressure regulation range 0.5 to 7 bar and operating pressure 2 to 12 bar. Filtering and regulating in one unit: the filter regulator MS9-LFR-NG-D6-EUV-DI-AG-PSI-AS cleans the air with a 40 µm grade of filtration and controls the pressure within 0.5 to 7 bar.

Advantages

  • Grade of filtration 40 µm, air purity class at the outlet ISO 8573-1:2010 [7:4:4].
  • Output pressure adjustable from 0.5 to 7 bar, pressure hysteresis max. 0.4 bar.
  • Condensate drain fully automatic, condensate volume up to 220 ml.
  • Pressure indication: with pressure gauge.
  • Actuator lock: can be closed with accessories.
  • Cleanroom suitability: class 7 according to ISO 14644-1.

Application

The filter regulator MS9-LFR-NG-D6-EUV-DI-AG-PSI-AS suits machines and systems that need filtered compressed air at a constant output pressure. Mounting position vertical ±5°. Operating medium compressed air to ISO 8573-1:2010 [7:4:-], Inert gas.

Technical data

TypeMS9-LFR-NG-D6-EUV-DI-AG-PSI-AS
Size9
SeriesMS
Actuator lockCan be closed with accessories
Mounting positionVertical ±5°
Grade of filtration40 µm
Condensate drainFully automatic
DesignDirectly actuated filter diaphragm regulator
Max. condensate volume220 ml
Controller functionOutput pressure constant, With primary pressure compensation, With secondary exhausting, With return flow function
Degree of condensate separation75 %
Pressure gauge (ANALOG) or Pressure display (DIGITAL)With pressure gauge
Operating pressure2 to 12 bar
Pressure regulation range0.5 to 7 bar
Max. pressure hysteresis0.4 bar
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:-], Inert gas
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Cleanroom suitability, measured according to ISO 14644-14Class 7 according to ISO 14644-1
Storage temperature5 to 60 °C
Air purity class at outputCompressed air to ISO 8573-1:2010 [7:4:4]
Media temperature-10 to 60 °C
Ambient temperature-10 to 60 °C
Pore size40 µm
Product weight2400 g
Type of mountingWith accessories
Material coveringReinforced PA
Material spin discPOM
Material filter carrierPOM
Note on materialsRoHS compliant
Material sub-baseDie-cast aluminium
Material mounting bracketDie-cast aluminium
Material housingDie-cast aluminium
Material module connectorDie-cast aluminium
Material membraneNBR
Material bowlWrought aluminium alloy
Material cup sealNBR
Material screenPA
Material separating platePOM
Material valve stemWrought aluminium alloy, NBR, POM
Weight (price list)3.3 kg
Weight3.3 kg
ManufacturerFesto
Hersteller-NrMS9-LFR-NG-D6-EUV-DI-AG-PSI-AS
EAN4052568211547
Zolltarifnummer84811005
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Control range max. [bar]7
Housing materialDie-cast aluminium
MediumCompressed air
Filter grade [µm]40
Druckregelbereich [bar]0,5 bis 7
Betriebsdruck max [bar]12
Temperaturbereich-10-60 °C
Temperature (max.)60
