Filter regulator 40 µm 0.5 to 7 bar MS9-LFR-NG-D6-EUM-DI-AG-PSI-AS - Festo 564124
The filter regulator MS9-LFR-NG-D6-EUM-DI-AG-PSI-AS filters the compressed air with a 40 µm grade of filtration and keeps the output pressure constant within 0.5 to 7 bar. Characteristics: operating pressure 1 to 20 bar, condensate drain manual, rotating and media temperature -10 to 60 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The key values of the filter regulator MS9-LFR-NG-D6-EUM-DI-AG-PSI-AS: grade of filtration 40 µm, pressure regulation range 0.5 to 7 bar and operating pressure 1 to 20 bar. The filter regulator MS9-LFR-NG-D6-EUM-DI-AG-PSI-AS filters the compressed air with a 40 µm grade of filtration and keeps the output pressure constant within 0.5 to 7 bar.
Advantages
- Grade of filtration 40 µm, air purity class at the outlet ISO 8573-1:2010 [7:4:4].
- Output pressure adjustable from 0.5 to 7 bar, pressure hysteresis max. 0.4 bar.
- Condensate drain manual, rotating, condensate volume up to 220 ml.
- Pressure indication: with pressure gauge.
- Actuator lock: can be closed with accessories.
- Cleanroom suitability: class 7 according to ISO 14644-1.
Application
As the input stage of a machine, the filter regulator MS9-LFR-NG-D6-EUM-DI-AG-PSI-AS cleans the compressed air and sets the working pressure for downstream consumers. Requirements for MS9-LFR-NG-D6-EUM-DI-AG-PSI-AS: mounting position vertical ±5° and operating medium inert gas.
Technical data
| Type | MS9-LFR-NG-D6-EUM-DI-AG-PSI-AS |
|---|---|
| Size | 9 |
| Series | MS |
| Actuator lock | Can be closed with accessories |
| Mounting position | Vertical ±5° |
| Grade of filtration | 40 µm |
| Condensate drain | Manual, rotating |
| Design | Directly actuated filter diaphragm regulator |
| Max. condensate volume | 220 ml |
| Controller function | Output pressure constant, With primary pressure compensation, With secondary exhausting, With return flow function |
| Degree of condensate separation | 75 % |
| Pressure gauge (ANALOG) or Pressure display (DIGITAL) | With pressure gauge |
| Operating pressure | 1 to 20 bar |
| Pressure regulation range | 0.5 to 7 bar |
| Max. pressure hysteresis | 0.4 bar |
| Operating medium | Inert gas |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Class 7 according to ISO 14644-1 |
| Storage temperature | -10 to 60 °C |
| Air purity class at output | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Media temperature | -10 to 60 °C |
| Ambient temperature | -10 to 60 °C |
| Pore size | 40 µm |
| Product weight | 2400 g |
| Type of mounting | With accessories |
| Material covering | Reinforced PA |
| Material spin disc | POM |
| Material filter carrier | POM |
| Note on materials | RoHS compliant |
| Material sub-base | Die-cast aluminium |
| Material mounting bracket | Die-cast aluminium |
| Material housing | Die-cast aluminium |
| Material module connector | Die-cast aluminium |
| Material membrane | NBR |
| Material bowl | Wrought aluminium alloy |
| Material cup seal | NBR |
| Material screen | PA |
| Material separating plate | POM |
| Material valve stem | Wrought aluminium alloy, NBR, POM |
| Weight (price list) | 3.2 kg |
| Weight | 3.2 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MS9-LFR-NG-D6-EUM-DI-AG-PSI-AS |
| EAN | 4052568211530 |
| Zolltarifnummer | 84811005 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Control range max. [bar] | 7 |
| Housing material | Die-cast aluminium |
| Filter grade [µm] | 40 |
| Druckregelbereich [bar] | 0,5 bis 7 |
| Betriebsdruck max [bar] | 20 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
