Filter regulator 40 µm MS9-LFR-G-D7-E-U-M-RG-BAR - Festo 588901
The filter regulator MS9-LFR-G-D7-E-U-M-RG-BAR combines filter and pressure regulator with a 40 µm grade of filtration, the output pressure can be set. Characteristics: size 9 of the MS series and condensate drain manual, rotating.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo filter regulator MS9-LFR-G-D7-E-U-M-RG-BAR at a glance: grade of filtration 40 µm and size 9. The filter regulator MS9-LFR-G-D7-E-U-M-RG-BAR combines filter and pressure regulator with a 40 µm grade of filtration, the output pressure can be set.
Advantages
- Grade of filtration 40 µm.
- Condensate drain manual, rotating.
- Pressure indication: red/green scale.
Application
As the input stage of a machine, the filter regulator MS9-LFR-G-D7-E-U-M-RG-BAR cleans the compressed air and sets the working pressure for downstream consumers.
Technical data
| Type | MS9-LFR-G-D7-E-U-M-RG-BAR |
|---|---|
| Series | MS |
| Size | 9 |
| Grade of filtration | 40 µm |
| Material bowl | Wrought aluminium alloy |
| Condensate drain | Manual, rotating |
| Pressure gauge (ANALOG) or Pressure display (DIGITAL) | Red/green scale |
| Weight (price list) | 3.4 kg |
| Weight | 3.4 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MS9-LFR-G-D7-E-U-M-RG-BAR |
| Zolltarifnummer | 84811005 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Filter grade [µm] | 40 |
