Filter regulator 5 µm 0.5 to 7 bar MS9-LFR-1-D6-C-U-V-A4 - Festo 595271
Filtering and regulating in one unit: the filter regulator MS9-LFR-1-D6-C-U-V-A4 cleans the air with a 5 µm grade of filtration and controls the pressure within 0.5 to 7 bar. Key values: port G1 and condensate drain fully automatic.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo filter regulator MS9-LFR-1-D6-C-U-V-A4 with grade of filtration 5 µm, pressure regulation range 0.5 to 7 bar and port G1. The filter regulator MS9-LFR-1-D6-C-U-V-A4 filters the compressed air with a 5 µm grade of filtration and keeps the output pressure constant within 0.5 to 7 bar.
Advantages
- Grade of filtration 5 µm.
- Output pressure adjustable from 0.5 to 7 bar.
- Condensate drain fully automatic.
- Pressure indication: prepared for G1/4.
- Pneumatic connection G1.
Application
The filter regulator MS9-LFR-1-D6-C-U-V-A4 suits machines and systems that need filtered compressed air at a constant output pressure.
Technical data
| Type | MS9-LFR-1-D6-C-U-V-A4 |
|---|---|
| Series | MS |
| Size | 9 |
| Pneumatic connection, port 1 | G1 |
| Pneumatic connection, port 2 | G1 |
| Pressure regulation range | 0.5 to 7 bar |
| Grade of filtration | 5 µm |
| Material bowl | Wrought aluminium alloy |
| Condensate drain | Fully automatic |
| Pressure gauge (ANALOG) or Pressure display (DIGITAL) | Prepared for G1/4 |
| Weight (price list) | 3.6 kg |
| Weight | 3.6 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MS9-LFR-1-D6-C-U-V-A4 |
| Zolltarifnummer | 84811005 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1 |
| Control range max. [bar] | 7 |
| Filter grade [µm] | 5 |
| Druckregelbereich [bar] | 0,5 bis 7 |
| Pneumatic connection | G1 |
