Soft-start and quick exhaust valve electrically actuated G1/2 MS6-SV-1/2-C-10V24P-S-A4 - Festo 578903
The soft-start and quick exhaust valve MS6-SV-1/2-C-10V24P-S-A4 pressurises the system slowly after switch-on and exhausts it quickly when switched off. At a glance: port G1/2 and valve function 3/2-way, single solenoid, closed, Soft-start function.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo soft-start and quick exhaust valve MS6-SV-1/2-C-10V24P-S-A4 at a glance: valve function 3/2-way, single solenoid, closed, Soft-start function and port G1/2. Gradual pressure build-up and quick exhausting: the soft-start and quick exhaust valve MS6-SV-1/2-C-10V24P-S-A4 protects actuators from abrupt start-up.
Advantages
- Safety function: Exhausting/category 1, performance level c, Prevention of unexpected start-up (pressurisation)/category 1, performance level c to DIN EN ISO 13849-1, DIN EN ISO 13849-2.
- Valve function 3/2-way, single solenoid, closed, Soft-start function, coil 24 V DC: 1.8 W.
- Pneumatic connection G1/2.
Application
The soft-start and quick exhaust valve MS6-SV-1/2-C-10V24P-S-A4 is used where the system must be pressurised gently and depressurised quickly when required.
Technical data
| Type | MS6-SV-1/2-C-10V24P-S-A4 |
|---|---|
| Series | MS |
| Size | 6 |
| Type of actuation | Electrical |
| Valve function | 3/2-way, single solenoid, closed, Soft-start function |
| Type of piloting | Piloted |
| Type of reset | Mechanical spring |
| Pneumatic connection, port 1 | G1/2 |
| Pneumatic connection, port 2 | G1/2 |
| Design | Piston gate valve |
| lap | Overlap |
| Performance Level (PL) | Exhausting/category 1, performance level c, Prevention of unexpected start-up (pressurisation)/category 1, performance level c |
| Conforms to standard | DIN EN ISO 13849-1, DIN EN ISO 13849-2 |
| Characteristic coil data | 24 V DC: 1.8 W |
| Electrical connection | 4-pin, according to IEC 61076-2-101 |
| Weight (price list) | 1.3 kg |
| Weight | 1.3 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MS6-SV-1/2-C-10V24P-S-A4 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/2 |
| Size BG | 6 |
| Actuation type | Electrical |
| Pneumatic connection | G1/2 |
