On/off valve manually actuated MS9-EM-NG-S-VS - Festo 562954
The manually actuated on/off valve MS9-EM-NG-S-VS switches the compressed air supply of the system on and off. Key values: flow rate 18000 l/min, operating pressure 0 to 20 bar and valve function 3/2-way, double solenoid.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The key values of the on/off valve MS9-EM-NG-S-VS: valve function 3/2-way, double solenoid, 18000 l/min flow rate and operating pressure 0 to 20 bar. The manually actuated on/off valve MS9-EM-NG-S-VS switches the compressed air supply of the system on and off.
Advantages
- Standard nominal flow rate (standardised to DIN 1343) 18000 l/min.
- Valve function 3/2-way, double solenoid.
- Operating pressure 0 to 20 bar.
- Actuator lock: rotary knob with detent.
- Cleanroom suitability: class 7 according to ISO 14644-1.
- Corrosion resistance class CRC 2, LABS (PWIS) conformity VDMA24364-B1/B2-L.
Application
The on/off valve MS9-EM-NG-S-VS is used as the main switching valve to pressurise and exhaust downstream components. For installation: mounting position any and operating medium compressed air to ISO 8573-1:2010 [7:4:4].
Technical data
| Type | MS9-EM-NG-S-VS |
|---|---|
| Series | MS |
| Size | 9 |
| Grid dimension | 90 mm |
| Design | Piston gate valve |
| Type of actuation | Manual |
| Sealing principle | Soft |
| Exhaust-air function | Cannot be throttled |
| Actuator lock | Rotary knob with detent |
| Type of reset | Force-pilot actuated |
| Type of piloting | Direct |
| Valve function | 3/2-way, double solenoid |
| Operating pressure | 0 to 20 bar |
| lap | Overlap |
| Standard nominal flow rate (standardised to DIN 1343) | 18000 l/min |
| Standard nominal flow rate 2-3 | 14100 l/min |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Note on materials | RoHS compliant |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Class 7 according to ISO 14644-1 |
| Media temperature | -10 to 60 °C |
| Sound pressure level | 93 dB(A) |
| Ambient temperature | -10 to 60 °C |
| Type of mounting | Inline installation, With accessories |
| Mounting position | Any |
| Product weight | 2400 g |
| Pneumatic connection, port 3 | G1 |
| Material piston slide | POM |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
| Weight (price list) | 3.6 kg |
| Weight | 3.6 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MS9-EM-NG-S-VS |
| EAN | 4052568210588 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Seal material | NBR |
| Housing material | Die-cast aluminium |
| Medium | Compressed air |
| Function | 3/2 bistable |
| Actuation type | Manually |
| Betriebsdruck max [bar] | 20 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
