Filter regulator 40 µm 0.3 to 7 bar MS6-LFR-1/2-D6-E-R-M-RG-AS - Festo 589898

Festo ✓ Original product Brand new

The filter regulator MS6-LFR-1/2-D6-E-R-M-RG-AS combines filter and pressure regulator with a 40 µm grade of filtration, the output pressure can be set within 0.3 to 7 bar. At a glance: port G1/2, flow rate 6200 l/min and operating pressure 0.8 to 20 bar.

Net
€84.44
excl. VAT
Item FES-589898
Manufacturer no. MS6-LFR-1/2-D6-E-R-M-RG-AS
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The key values of the filter regulator MS6-LFR-1/2-D6-E-R-M-RG-AS: grade of filtration 40 µm, pressure regulation range 0.3 to 7 bar and 6200 l/min flow rate. The filter regulator MS6-LFR-1/2-D6-E-R-M-RG-AS combines filter and pressure regulator with a 40 µm grade of filtration, the output pressure can be set within 0.3 to 7 bar.

Advantages

  • Grade of filtration 40 µm, air purity class at the outlet ISO 8573-1:2010 [7:4:4].
  • Output pressure adjustable from 0.3 to 7 bar, pressure hysteresis max. 0.25 bar.
  • Standard nominal flow rate (standardised to DIN 1343) 6200 l/min.
  • Condensate drain manual, rotating, condensate volume up to 38 ml.
  • Pressure indication: red/green scale.
  • Actuator lock: rotary knob with detent, can be closed with accessories.

Application

The filter regulator MS6-LFR-1/2-D6-E-R-M-RG-AS suits machines and systems that need filtered compressed air at a constant output pressure. Requirements for MS6-LFR-1/2-D6-E-R-M-RG-AS: mounting position vertical ±5° and operating medium compressed air to ISO 8573-1:2010 [-:4:-], Inert gas.

Technical data

TypeMS6-LFR-1/2-D6-E-R-M-RG-AS
Size6
SeriesMS
Actuator lockRotary knob with detent, can be closed with accessories
Mounting positionVertical ±5°
Grade of filtration40 µm
Condensate drainManual, rotating
DesignFilter regulator with pressure gauge
Max. condensate volume38 ml
Controller functionOutput pressure constant, With secondary exhausting
Bowl guardPlastic bowl guard
Degree of condensate separation75 %
Pressure gauge (ANALOG) or Pressure display (DIGITAL)Red/green scale
Operating pressure0.8 to 20 bar
Pressure regulation range0.3 to 7 bar
Max. pressure hysteresis0.25 bar
Standard nominal flow rate (standardised to DIN 1343)6200 l/min
Operating mediumCompressed air to ISO 8573-1:2010 [-:4:-], Inert gas
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Storage temperature-10 to 60 °C
Suitable for use with foodSee supplementary material information
Air purity class at outputCompressed air to ISO 8573-1:2010 [7:4:4]
Media temperature-10 to 60 °C
Ambient temperature-10 to 60 °C
Pore size40 µm
Product weight875 g
Type of mountingFront panel mounting, Inline installation, With accessories
Pneumatic connection, port 1G1/2
Pneumatic connection, port 2G1/2
Note on materialsRoHS compliant
Material control panelPA, POM
Material sealsNBR
Material housingDie-cast aluminium
Material membraneNBR
Material bowlPC
Material separating platePOM
Weight (price list)1 kg
Weight1 kg
ManufacturerFesto
Hersteller-NrMS6-LFR-1/2-D6-E-R-M-RG-AS
EAN4052568395117
Zolltarifnummer84811005
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/2
Size BG6
Control range max. [bar]7
Seal materialNBR
Housing materialDie-cast aluminium
MediumCompressed air
Filter grade [µm]40
Druckregelbereich [bar]0,3 bis 7
Betriebsdruck max [bar]20
Pneumatic connectionG1/2
Temperaturbereich-10-60 °C
Temperature (max.)60
