Proportional-pressure regulator MPPES-3-1/8-6-010 - Festo 187352

Name: Proportional-pressure regulator MPPES-3-1/8-6-010 - Festo 187352
Brand: Festo
SKU: FES-187352
Price: 1041.68 EUR
Availability: InStock

Festo ✓ Original product Brand new

Net

€1,041.68

excl. VAT

Item FES-187352

Manufacturer no. MPPES-3-1/8-6-010

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Technical data

Nominal size, supply	3 mm
Nominal size, exhaust	2 mm
Type of actuation	Electrical
Sealing principle	Soft
Mounting position	Any
Design	Directly actuated piston regulator
Short circuit current rating	For all electrical connections
Safety instructions	Safety position MPPES: if the power supply cable is interrupted, the output pressure drops to 0 bar.
Reverse polarity protection	For all electrical connections
Valve function	3-way proportional-pressure regulator, closed
Operating pressure	8 bar
Pressure regulation range	0 ... 6 bar
Inlet pressure 1	7 ... 8 bar
Max. pressure hysteresis	0.01 bar
Switching time off	280 ms
Switching time on	210 ms
Operational voltage range DC	18 ... 30 V
Nominal operating voltage DC	24 V
Residual ripple	10%
SETPOINT/ACTUAL values	Voltage type 0 - 10 V
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Approval	RCM
KC mark	KC-EMV
CE mark (see declaration of conformity)	To EU EMC Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)	To UK RoHS instructions
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B2-L
Media temperature	0 ... 60 °C
Degree of protection	IP65
Ambient temperature	0 ... 50 °C
Product weight	915 g
Electrical connection	8-pin, M16x0.75, Plug, To DIN 45326, Round design
Type of mounting	With through-hole
Pneumatic connection, port 1	G1/8
Pneumatic connection, port 2	G1/8
Pneumatic connection, port 3	G1/8
Note on materials	RoHS compliant
Material housing	Wrought aluminium alloy
Material membrane	NBR
Weight	1 kg
Manufacturer	Festo
Hersteller-Nr	MPPES-3-1/8-6-010
EAN	4052568014827
Zolltarifnummer	84811099
GPSR Herstellerdaten	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Artikelzustand	New
Artikel-Authentizität	Original product
